background image

International Office: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA 815-433-5100 Fax 433-5104

European Office: Westlink Commercial Park Oranmore Co. Galway Ireland +353 91 792444 Fax +353 91 792445

[email protected]

[email protected]

5 Port Industrial ethernet switch

with 4 Poe Ports

EIRP305-24V-T

regulatory

Safety/Hazardous Location

UL/cUL Class I, Division 2,

Groups A, B, C and D

EMC

FCC Class A

CE EN61000-6-2

CE EN61000-6-4

CE EN61000-4-2 (ESD)

CE EN61000-4-3 (RS)

CE EN61000-4-4 (EFT)

CE EN61000-4-5 (Surge)

CE EN61000-4-6 (CS)

CE EN61000-4-8 (Magnetic Field)

Free Fall

IEC60068-2-32

Shock

IEC60068-2-27

Vibration

IEC60068-2-6

ieee standards

IEEE 802.3

802.3. 10Base-T Ethernet

IEEE 802.3u

100Base-TX and 100Base-FX Fast Ethernet

IEEE 802.3x

Flow Control and Back Pressure

IEEE802.3af

Power Over Ethernet

network sPeciFications

Architecture

Back-plane (Switching Fabric): 1.0 Gbps

Transfer Rate

14,880 pps Ethernet Port

148,800 pps Fast Ethernet Port

Buffer

448 Kbits

MAC Table

2K

Other

Broadcast Storm Filtering

CSMA/CD

sPecIFIcAtIons

interFace

RJ-45 Ports

5 x 10/100BaseT, Auto MDI/MDI-X

ESD Protection

6000V ESD Protection

PoE

802.3af End-point Alternative A (4 Ports)

Positive (VCC+): Pins 1 and 2

Negative (VCC-): Pins 3 and 6

Data: Pins 1, 2, 3, and 6

LED Indicators

P1 (Power 1), P2 (Power 2),

Fault (Power Fault),

RJ-45 Ports have 2 LED’s to indicate LINK

and activity. FWD LEDs for PoE status.

Power

Input Voltage

Dual 24 / 48 VDC Inputs

Reverse Polarity Protection

Power Connection

Removable Terminal Block

Wire Size

12 to 24 AWG

Power Use

3.4 Watts (without PoE)

67 Watts (full load PoE)

Fault Output

1 Relay Output – Normally Closed

EFT Protection

3000 V EFT Protection

enVironMental

Operating Temperature

- 40 to 75°C (-40 to 167°F)

Storage Temperature

- 40 to 85°C (-40 to 185°F)

Operating Humidity

0 to 95%

Mechanical

Enclosure

IP30 Metal Enclosure

Mounting

35 mm DIN Rail or Panel Mount Attachments

Dimensions

4.86 x 14 x 9.5 cm (1.91 x 5.51 x 3.74 in )
