THE INDUSTRIAL NETWORK COMPANY
BENEFITS
Industrial Network Switch
• Compact Size / Small Footprint
• Extended Environmental Specifi cations
• Hardened Metal DIN-Rail Enclosure
• High Performance
• High MTBF >2M Hours
• ESD Protection Diodes on RJ-45 Ports
• Surge Protection Diodes on Power Inputs
Ease of Use
• Plug & Play Operation
• Auto Sensing 10/100BaseTX
• Auto Negotiation Full/Half Duplex
• MDIX Auto Cable Sensing
• Unmanaged Operation
Increased Performance
• Full Wire Speed Capable
• Full Duplex Capable
• Eliminates Network Collisions
• Increases Network Determinism
Ordering Information
104TX Four 10/100BaseTX Ports
NTPS-24-1.3 DIN-Rail Power Supply
[email protected] Amp
104TX SPECIFICATIONS
Case Dimensions
Height: 2.9" (7.3cm)
Width: 1.5" (3.8 cm)
Depth: 3.6" (9 cm)
Weight: 0.6 lbs. (0.28 kg)
DIN-Rail: 35mm
Electrical
Input Voltage: 10-30 VDC
Steady Input Current: 215mA@24V
Inrush: 7.8Amp/0.7ms@24V
Environmental
Operating Temperature: -40 o C to 80 o C
Storage Temperature: -40 o C to 85 o C
Operating Humidity: 10% to 95%
(Non Condensing)
Operating Altitude: 0 to 10,000 ft.
Reliablity
MTBF: >2 Million Hours
Network Media
10BaseT: >Cat3 Cable
100BaseTX: >Cat5 Cable
Connectors
10/100BaseTX: Four (4) RJ-45 TX
Copper Ports
Recommended Wiring Clearance
Front: 2" (5.08 cm)
Top: 1" (2.54 cm)
Regulatory Approvals
FCC Title 47 Part 15 Class A
ICES-003- Class A
CE: EN61000-6-2,4
EN61000-4-2,3,4,5,6
EN55011 Class A
UL Listed (US and Canada) per ANSI/ISA-12.12.01-2000,
Class I, Div 2, Groups A,B,C,D,T4A
ABS Type Approval for Shipboard Applications
DNV Type Approval Certifi cation
EN50155 for Railway Applications
RoHS Compliant; GOST-R Certifi ed
Designed to comply with:
IEEE 1613 for Electric Utility Substations;
and NEMA TS1/TS2 for Traffi c Control Equipment
