SPECIFICATION

MODEL

DC VOLTAGE

RATED CURRENT

CURRENT RANGE

RATED POWER

OUTPUT

VOLTAGE ADJ. RANGE

LINE REGULATION

LOAD REGULATION

SETUP, RISE TIME

HOLD UP TIME (Typ.)

VOLTAGE RANGE

Note.6

FREQUENCY RANGE

EFFICIENCY (Typ.)

INPUT

INRUSH CURRENT (Typ.)

LEAKAGE CURRENT

OVER TEMPERATURE

SAFETY STANDARDS

HARMONIC CURRENT

EMS IMMUNITY

WORKING TEMP.

Note.5

WORKING HUMIDITY

STORAGE TEMP., HUMIDITY

DC OK REALY CONTACT RATINGS (max.)

TEMP. COEFFICIENT

VIBRATION

MTBF

DIMENSION

OTHERS

NOTE

PACKING

OVERLOAD

OVER VOLTAGE

AC CURRENT (Typ.)

800ms, 150ms/400VAC

2000ms, 150ms/230VAC at full load

18ms / 400VAC

at full load

16ms / 230VAC

180 ~ 550VAC

254 ~ 780VDC

47 ~ 63Hz

92%

1.6A/400VAC

4A/230VAC

56 ~ 65V

93%

COLD STAR 50A

<3.5mA / 530VAC

29 ~ 33V
Protection type : Shut down o/p voltage, auto-recovery after 1 minute if the fault condition is removed

95

5

(TSW) detect on heatsink of power switch

Protection type : Shut down o/p voltage, recovers automatically after temperature goes down

UL508 approved, Design refer to GL

Compliance to EN55022 (CISPR22), EN61204-3 Class B

Compliance to EN61000-3-2,-3

-30 ~ +70

(Refer to output load derating curve)

60Vdc/0.3A, 30Vdc/1A, 30Vac/0.5A resistive load

20 ~ 95% RH non-condensing

-40 ~ +85

, 10 ~ 95% RH

0.03%/

(0 ~ 50

Component:10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes; Mounting: Compliance to IEC60068-2-6

112.8Khrs min.

MIL-HDBK-217F (25

)

Compliance to EN61000-4-2,3,4,5,6,8,11, ENV50204, EN55024, EN61000-6-2 (EN50082-2), EN61204-3, heavy industry level, criteria A approved

85.5*125.2*128.5mm (W*H*D)

1.7Kg; 8pcs/14.6Kg/0.9CUFT

WDR-480-48

48V

10A

0 ~ 10A

480W

150mVp-p

48 ~ 55V

1.0%

0.5%

1.0%

WDR-480-24

24V

20A

0 ~ 20A

480W

100mVp-p

24 ~ 28V

1.0%

0.5%

1.0%

Features :

WDR-480

series

WITHSTAND VOLTAGE

ISOLATION RESISTANCE

I/P-O/P:3KVAC

I/P-FG:1.5KVAC

O/P-FG:0.5KVAC

O/P-DC OK:0.5KVAC

I/P-O/P, I/P-FG, O/P-FG:>100M Ohms / 500VDC / 25

/ 70% RH

EMI CONDUCTION & RADIATION

ENVIRONMENT

SAFETY &

FUNCTION

EMC

(Note 4)

PROTECTION

RIPPLE & NOISE (max.)

Note.2

VOLTAGE TOLERANCE

Note.3

1. All parameters NOT specially mentioned are measured at 400VAC input, rated load and 25

of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives.

5. Installation clearances : 40mm on top, 20mm on the bottom, 5mm on the left and right side are recommended when loaded permanently with full power.

In case the adjacent device is a heat source, 15mm clearance is recommended.

6. Derating may be needed under low input voltage. Please check the derating curve for more details.

480W Single Output Industrial DIN RAIL Power Supply

Single and two phase wide input range 180~550VAC

High efficiency 93% and low power dissipation

Protections: Short circuit / Overload / Over voltage / Over temperature

Cooling by free air convection

Can be installed on DIN rail TS-35/7.5 or 15

UL 508(industrial control equipment)approved

EN61000-6-2(EN50082-2) industrial immunity level

Built-in DC OK relay contact

100% full load burn-in test

3 years warranty

File Name:WDR-480-SPEC 2010-09-06

105 ~ 130% rated output power

Protection type : Constant current limiting, unit will shut down after 3 sec. ,auto-recovery after 1 minute if the fault condition is removed
