PRODUCT FEATURES

• Eight 10/100BaseTX RJ-45 ports
• Two 100BaseFX ports, ST or SC style
• Two SFP gigabit ports
• -40

o

C to 70

o

C operating temperature

• Onboard temperature sensor
• ESD and surge protection diodes on all ports
• Auto-sensing 10/100BaseTX, duplex, and MDIX
• Store-and-Forward technology
• Rugged DIN-rail enclosure
• Redundant power inputs (10-49VDC)

FULLY MANAGED FEATURES
• SNMP v1, v2, v3 and web browser management
• Confi guration backup via optional SD card
• Detailed ring map and fault location charting
• N-Ring

technology with ~30ms healing

• N-Link

redundant N-Ring coupling

• N-View

OPC monitoring

• RSTP - IEEE 802.1D
• IGMP auto-confi guration
• 802.1Q tag VLAN and port VLAN
• 802.1p QoS, port QoS, and DSCP
• EtherNet/IP

CIP messaging

• LLDP (Link Layer Discovery Protocol)
• Trunking and port mirroring
• 802.1d, 802.1w, 802.1D RSTP
• DHCP server, option 82 relay, option 61, IP fallback
• Local port IP addressing
• Port security—MAC address-based

THE INDUSTRIAL NETWORK COMPANY

7012FX2

7000 SERIES

Fully-Managed Switch

BUILT FOR EXTREME CONDITIONS

The compact N-TRON

®

7012FX2 fully-managed industrial Ethernet switch is ideal

for industrial and utility applications that demand extreme performance under harsh
conditions. Housed in a rugged industrial metal enclosure, the switch offers a powerful
combination of eight 10/100BaseTX copper ports, two 100Base fi ber ports, two SFP
gigabit ports, and redundant power inputs for robust network support. The device boasts
exceptional MTBF and extended tolerances to shock, vibration, temperature fl uctuations
and noise—common elements in factory fl oor control networks, utilities, wastewater
treatment, wind turbines, rail car, intelligent traffi c control and transportation applications.

ADVANCED RING TECHNOLOGY

Advanced N-Ring technology provides expanded capacity, detailed fault diagnostics,
and fast ~30ms healing time for N-TRON-based rings. The integrity of the ring is
continually checked by sending heart beat packets around the network. If an error is
detected, the ring converts to a linear topology within ~30ms and communication is
immediately restored. A detailed ring map and fault location chart may be accessed by
the ring manager's web browser or the OPC server. Each N-Ring accommodates up
to 250 fully-managed N-TRON switches. To establish redundancy, N-Link technology
easily connects multiple N-Rings, creating additional pathways to critical applications
and increasing overall resiliency.

MONITORING OPTIONS

N-TRON provides multiple tools to monitor the 7012FX2. The robust web-based
interface provides a convenient dashboard to view and confi gure switch options, as
well as monitor network traffi c, alarms, and trend information. For tightly controlled
environments, N-View OPC server software easily combines with HMI control and
monitoring applications to form a complete surveillance solution for N-View-enabled
switches. The iSNMP Software Suite is also available for link and status monitoring.
For local monitoring, each switch features confi gurable LEDs to indicate power failure
and N-Ring status.

EASY TO USE

The 7012FX2 features auto-sensing and auto-confi guring 10/100BaseTX ports. Each
copper port automatically negotiates for maximum speed and performance but can
be hardcoded through the user interface. A high-speed processor allows wire speed
capability on all ports simultaneously.

www.n-tron.com

R U G G E D • R E L I A B L E • A F F O R D A B L E
