422PS Power Supplies - pg. 2/3
© B&B Electronics
APPROVED By:
DRAWN By:
RANDY HANCK
SCALE : 1X
APRIL 15, 1994
DATE:
(26.7)
MOLDED STRAIN RELIEF.
7. SAFETY COMPLIANCE:
UNIT IS UL LISTED AND CSA APPROVED.
CUSTOM RIGHT ANGLE TYPE
DC POWER MINI-PLUG, MOLDED
WITH STRAIN RELIEF. .10 (2.5 mm)
DIAMETER SHAFT. TIP POSITIVE
6. OUTPUT CONNECTOR:
24 AWG X 2 CONDUCTORS
FLAT TYPE. (PVC) WITH
LENGTH: 72.0 MIN. +/- 2.0
DC CORD: BLACK COLOR
5. OUTPUT CORD:
MATERIAL : BLACK COLOR
HIGH IMPACT PLASTIC
(1830)
ABS OR NORYL
4. HOUSING:
MECHANICAL:
(43.0)
(50.0)
INPUT: 120VAC 60Hz 3W
MADE IN TAIWAN R.O.C.
OUTPUT: 12VDC 100mA
PLUG-IN CLASS 2 TRANSFORMER
UL CSA
AC ADAPTOR
MODEL NO: AD-1210
PART NO: AD1210BB3
B&B ELECTRONICS
OTTAWA, ILLINOIS 61350
(MM)
INCH
1.69
DC OUTPUT 12 VOLTS @ 100 mA.
ADAPTER, AC 120 VOLT INPUT
MODEL NUMBER:
-
B&B ELECTRONICS Mfg. Co.
(11.5)
TITLE
422PS2A.SKD
FILE =
OTTAWA , IL 61350
(22.1)
0.87
1.05
.45
SHEET 2 of 3
(815) 433-5100
+
422PS
Rev.
0.10
(2.5)
1.52
(38.5)
REVISIONS
DESCRIPTION
(56.0)
2.20
DATE
.70
(17.8)
APP.
