316TX-N Specifi cations
Switch Properties
Number of MAC Addresses: 4,000
Latency Typ.:
2.1 μs
Backplane Speed: 2.6Gb/s
Switching Method:
Store & Forward
Case Dimensions
Height: 7.4"
(18.8cm)
Width: 2.3" (5.8cm)
Depth: 3.5" (8.9cm)
Weight: 1.9 lbs (0.9kg)
Din-Rail: 35mm
Electrical
Redundant Input Voltage:
10-30 VDC
Input Current: 400 mA@24V
Inrush: 7.0Amp/0.8ms@24V
BTU/hr: 21.3@24V
Environmental
Operating and Storage Temp: -40ºC to 85ºC
Operating Humidity:
10% to 95%
(Non Condensing)
Operating Altitude: 0 to 10,000 ft.
Shock and Vibration (bulkhead mounting)
Shock:
200g @ 10ms
Vibration/Seismic: 50g, 5-200Hz, Triaxial
Reliability
MTBF:
>2 Million Hours
Network Media
10BaseT:
>Cat3 Cable
100BaseTX: >Cat5 Cable
100BaseFX
Connectors
10/100BaseTX:
Sixteen (16) RJ-45 Copper Ports
Serial Confi guration Port
Com Parameters: 9600,n,8,1
Recommended Wiring Clearance
Front:
2" (5.08 cm)
Side: 1" (2.54 cm)
Regulatory Approvals
FCC (CFR 47, Part 15, Subpart B, Class A and ANSI C63.4)
ICES-003
CE (IEC 60068: 2-1/2/6/30 and IEC 60533-7)
UL/cUL: Class I, Div 2, Groups A, B, C, and D; T4
(ANSI/ISA 12.12.01-2007)
GOST-R Certifi ed, RoHS Compliant
Designed to comply with:
EN 60079-0/15 ATEX
IACS UR E10 (ABS Type-Approval)
IEC 61850-3 and IEEE 1613 (Elec. Power Sub-stations)
NEMA TS1/TS2 for Traffi c Control
