SpecificationS
Technology
Wireless Technology
IEEE 802.11 a/b/g/n, Wi-Fi Compliant
Wired Interface
2 ports, RS-232/422/485, (RS-232/422 4 wire or RS-485
2 wire)
10/100 Ethernet port (Bridge, Router (NAT3) Modes)
Software selectable
Frequency
2.4~2.4835 GHz (US/Canada/Europe)
2.4~2.497 GHz (Japan)
5.150 ~ 5.350 GHz
5.725 ~ 5.825 GHz
Modulation Technology DSSS, CCK, OFDM
Modulation Type
DBPSK, DQPSK, CCK, BPSK, QPSK, 16QAM, 64QAM
Network Access
Modes
Infrastructure (Client), Ad Hoc
Channels
US/Canada: 11 Channels 802.11b/g
13 Channels 802.11a
Europe:
13 Channels 802.11b/g
19 Channels 802.11a
France:
4 Channels 802.11b/g
Japan:
14 Channels 802.11b
13 Channels 802.11g
23 Channels 802.11a
Wireless Data Rates
802.11a/g 54, 48, 36, 24, 18, 12, 9, 6 Mbps
802.11b = 11, 5.5, 2, 1 Mbps
802.11n 65, 58.5, 42, 39, 26, 19.5, 13, 6.5 Mbps
Network Protocols
TCP/IP, ARP, ICMP, DHCP, DHS, UDAP, TFTP, UDP, PING,
HTTP, FTP
Receive Sensitivity
802.11 b/g
54Mb/s = -72 dBm
36Mb/s = -78 dBm
18Mb/s = -84 dBm
6Mb/s = -89 dBm
11Mb/s = -86 dBm
1Mb/s = -92 dBm
Receive Sensitivity
802.11 a
54Mb/s = -74 dBm
36Mb/s = -80 dBm
36Mb/s = -80 dBm
6Mb/s = -90 dBm
Wireless Security
Open, WEP 64 & 128 bit, WPA-PSK (TKIP), WPA2-PSK
(AES), 802.1x (EAP), WPA-Enterprise, WPA2-Enterprise,
EAP-TLS/MSCHAPv2, EAP-TTLS/MSCHAPv2, EAP-TTLS
(MD5), EAP-PEAPv0/MSCHAPv2, LEAP
- Zero host security footprint
- Advanced certificate storage and management
Secure
Communications
- SSH and SSL tunneling
- Encrypted configuration
Transmit Power
802.11b 15 dBm (31.6mW)
802.11g 12.6dBm (18.12mW)
802.11a 17 dBm (50.1mW)
Power
Input Voltage
5-36VDC +/-5%, 500mA (MAX)
Power Connection
2-position terminal block, 2.1mm barrel jack;
PoE 802.3af
Power Use
2.5W at 5VDC
Supply In-rush Current 3000mA (MAX) for 20ms
PoE
PoE using a 802.3af Class 1 PSE device
LeD InDIcators
4 LEDs
COMM, LINK, POWER, POST (Power on Self Test)
envIronmentaL
Operating Temperature -40° to +85°C
Storage Temperature
-40° to +85°C
Op. Humidity
5% - 95% (non-condensing)
mechanIcaL
Antenna
RP-SMA Omni-directional 2dBi 2.4/5 GHz Antenna
Vibration
20G peak-to-peak, 20Hz-2KHz swept
Shock
1500G peak-to-peak, 0.5mS duration
Enclosure
Metal Enclosure
Mounting
Panel mount, optional DIN rail brackets
Dimensions
120.14 x 120.12 x 29.21 mm (4.89 x 4.73 x 1.15in)
reguLatory aPProvaLs
FCC Part 15.247, Class B Sub C Modular Approval
Industry Canada RSS-210
CE
ETSI EN300-328 v1.7.1
ETSI 60950-1
Directive 2004/108/EC
ETSI EN 55022:2006 + A1:2007 (emissions)
ETSI EN 55024:1998 + A1:2001
ETSI EN 55024:1998 + A2:2003 (immunity)
FCC Part 15 Subpart B:2007
- Part 15.107(b) (conducted emissions, Class A)
- Part 15.109(g) (radiated emissions, Class B)
Industry Canada ICES-003:2004, Issue 4
AS/NZS CISPR 11:2004 (Australia/New Zealand)
RoHS and WEEE Compliant
M2M Dual band (2.4gHz, 5gHz)
Ethernet bridge/Router; Serial Server
