THE INDUSTRIAL NETWORK COMPANY
1005TX SPECIFICATIONS
Case Dimensions
Height: 4.0" (10.2 cm)
Width: 1.0" (2.6 cm)
Depth: 3.7 (9.4 cm)
Weight: 0.61 lbs. (0.27 kg)
DIN-Rail: 35mm
Electrical
Input Voltage: 10-30 VDC
Steady Input Current: 230mA@24V
Inrush: 13Amp/61us@24V
Environmental
Operating Temperature: -40 o C to 85 o C
Storage Temperature: -40 o C to 85 o C
Operating Humidity: 10% to 95%
(Non Condensing)
Operating Altitude: 0 to 10,000 ft.
Reliablity
MTBF: >2 Million Hours
Network Media
10BaseT: >Cat3 Cable
100BaseTX: >Cat5 Cable
1000BaseT: >Cat5e Cable
Connectors
10/100/1000BaseT: Five (5) RJ-45 TX
Copper Ports
Recommended Wiring Clearance
Front: 2" (5.08 cm)
Top: 1" (2.54 cm)
BENEFITS
Industrial Network Switch
• Compact Size / Smaller Footprint
• Extended Environmental Specifi cations
• Hardened Metal DIN-Rail Enclosure
•
High Performance
• High MTBF >2M Hours
• ESD Protection Diodes on RJ-45 Ports
• Surge Protection Diodes on Power Inputs
Ease of Use
• Plug & Play Operation
• Auto Sensing 10/100/1000BaseT
• Auto Sensing Full/Half Duplex
• MDIX Auto Cable Sensing
•
Unmanaged Operation
Increased Performance
• Full Wire Speed Capable
• Full Duplex Capable
• Eliminates Network Collisions
• Increases Network Determinism
Regulatory Approvals
FCC/CE (CFR 47, Part 15, Subpart B, Class A)
EN 61000-6-2/4, IEC 61000-4-2/3/4/5/6
EN 55011, ICES-003
UL/cUL: Class I, Division 2, Groups A, B, C and D; T4
UL 508, ICE and ANSI/ISA-12.12.01-2007
ABS Type Approval for Shipboard Applications
DNV Type Approval Certifi cation
RoHS Compliant
Designed to comply with:
IEEE 1613 for Electric Utility Substations
NEMA TS1/TS2 for Traffi c Control
REV 100513
