BENEFITS
PoE Industrial Network PSE
• Compact Size / Small Footprint
• Ability to Power Devices via LAN
• Eliminates need for Costly Electrical Wiring
• Extended Environmental Specifi cations
• Hardened Metal DIN-Rail Enclosure
• High Performance
• High MTBF >2M Hours
• ESD Protection Diodes on RJ-45 Ports
• Surge Protection Diodes on Power Inputs
Ease of Use
• Plug & Play Operation
• Unmanaged Operation
• Ideal for Network Expansion
• Auto-Detection of Connected PoE Devices
• Dual PoE Status LED's per port
Increased Performance
• Full Wire Speed Communications
• Auto-Disconnect of PoE Port if Fault is Detected
Regulatory Approvals
FCC Title 47 Part 15 Class A
UL Listed (US and Canada) per ANSI/ISA-12.12.01-2000,
Class I, Div 2, Groups A,B,C,D,T4A
ICES-003- Class A
CE: EN61000-6-2,4
EN61000-4-2,3,4,5,6
EN55011
ABS Type Approval for Shipboard Applications
DNV Type Approval Certifi cation
EN50155 for Railway Applications
GOST-R Certifi ed; RoHS Compliant
Designed to comply with:
IEEE 1613 for Electric Utility Substations;
NEMA TS1/TS2 for Traffi c Control Equipment
Ordering Information
100-POE4 Four Pair 10/100BaseTX Ports
Four POE Ports
NTPS-48-5 DIN-Rail Power Supply
48V@ 5 Amp
100-POE4 SPECIFICATIONS
Case Dimensions
Height: 3.5"
(8.9cm)
Width: 1.5" (3.8 cm)
Depth: 3.6" (9.0 cm)
Weight: 0.7 lbs. (0.32 kg)
DIN-Rail: 35mm
Electrical
Input Voltage:
46-49 VDC
Steady Input Current
Under Full Load:
1.6 A@48V
Steady Input Current
Under No Load:
30mA@48V
Inrush: 27Amp/1.5ms@48V
Environmental
Operating Temperature:
-40 o C to 85 o C
Storage Temperature: -40 o C to 85 o C
Operating Humidity: 10% to 95%
(Non Condensing)
Operating Altitude: 0 to 10,000 ft.
Reliablity
MTBF:
>2 Million Hours
Network Media
10BaseT: >Cat3
Cable
100BaseTX: >Cat5 Cable
Connectors
10/100BaseTX:
Eight (8) RJ-45
Copper Ports
Recommended Wiring Clearance
Front:
2" (5.08 cm)
Top: 1" (2.54 cm)
THE INDUSTRIAL NETWORK COMPANY
REV 090805
