Features
www.advantech.com/products Online Download
EKI-1351
EKI-1352
Supports 802.11g and 802.11b
Supports wireless LAN Ad-Hoc and Infrastructure modes
Provides COM port redirection (Virtual COMport), TCP/IP and UDP modes
Supports standard socket and winsock networking programming
Provides multiple networking architectures: polling, event handling,
serial tunneling
Allows a maximum of 5 host PCs to access with command response mode
using UDP protocol
Auto-searching Windows configuration utility
Supports DIN-rail or panel mounting 







Specifications
Ethernet Communications
Compatibility IEEE 802.11g and 802.11b
Speed 54/11 Mbps
Connectors Wireless
Serial Communications
Type RS-232/422/485
Connectors EKI-1351: 1 x DB9
EKI-1352: 2 x DB9
Ports EKI-1351: 1
EKI-1352: 2
Data Bits 5, 6, 7, 8
Stop Bits 1, 1.5, 2
Parity Bits Odd, even, none, space, mark
Baud Rate 50bps ~ 921kbps
2 ports up to 460k bps simultaneously
Data Signals RS-232: TxD, RxD, CTS, RTS, DTR, DSR, DCD, RI, GND
RS-422: TxD+, TxD-, RxD+, RxD-, GND
RS-485: Data+, Data-, GND
Software
Driver Supported 2000/XP/Vista(x86)
Utility Software Advantech Serial Device Server Configuration Utility
Operation Modes COM port redirection mode (virtual COM port)
TCP Server (polling) mode
TCP Client (event handling) mode
Pair connection without AP (Peer to Peer)














Mechanics
Dimensions (W x H x D) 37 x 140 x 95 mm
Enclosure
Metal with solid mounting hardware
Mounting DIN-rail, panel
General
Certifications CE, FCC class B
LED Indicators System: Power, status
WLAN: Quality, Fail, Link/Active
Serial: TX/RX
Power
Power Input 2 x Unregulated 12 ~ 48 V
DC
Power Consumption EKI-1351: 3.5 W
EKI-1352: 4 W
Protection
Serial Protection 15 KV ESD
Environment
Operating Temperature 0 ~ 50° C (32 ~ 122° F)
Storage Temperature -20 ~ 80° C (-4 ~ 176° F)
Operating Humidity
20 ~ 95% (non-condensing)
Storage Humidity 0 ~ 95% (non-condensing)
Ordering Information
EKI-1351 1-port RS-232/422/485 to 802.11b/g WLAN Serial
Device Server
EKI-1352 2-port RS-232/422/485 to 802.11b/g WLAN Serial
Device Server














Introduction
EKI-1351 and EKI-1352 are wireless serial device servers that bring RS-232/422/485 to wireless Ethernet. They allow nearly any device with serial ports to connect and share an
Wireless Ethernet network. EKI-1351 and EKI-1352 provide a quick, simple and cost-effective way to bring the advantages of remote management and data accessibility to thousands
of devices that cannot connect to a network.
With EKI-1351 and EKI-1352, your existing serial devices can be used with the most popular operating systems on the market. There is no need to write special drivers for specific
operating systems. Moreover, you can make serial devices communicate with other devices peer-to-peer, without any intermediate host PCs and software programming. That saves a
lot of cost and effort. In addition, you can actively request data or issue commands from the RS-232/422/485 side or Wireless Ethernet side. This data can be sent bilaterally. Thus,
the EKI-1351 and EKI-1352 are especially suitable for remote monitoring environments such as security systems, factory automaton, SCADA, transportation and more.
1-port RS-232/422/485 to 802.11b/g WLAN
Serial Device Server
2-port RS-232/422/485 to 802.11b/g WLAN
Serial Device Server
NEW
