2
The diagram below illustrates the route that data will take according to the above
guidelines. Another path in the opposite direction is needed to complete this
installation.
Specifications
Environmental
Operating Temperature
32° - 104° F (0° - 40° C)
Storage Temperature
0° - 160° F (-20° - 70° C)
Humidity
5 - 95% (non-condensing)
Fiber Optic Specifications
Insertion Loss: 1.4dB @ 1550 nm, 1.5 dB @ 1300 nm (Max values)
For fiber optic specifications, please visit:
http://www.imcnetworks.com/adocs/fcs.asp
IMC Networks Technical Support
Tel: (949) 465-3000 or (800) 624-1070 (in the U.S. and Canada);
+32-16-550880 (Europe)
Fax: (949) 465-3020
E-Mail: [email protected]
Web: www.imcnetworks.com
