secure, rugged wi-Fi access point modules
apMn-Q551 Series
The AirborneM 2 M line of highly-integrated 802.11 wireless access
point modules allow OEMs to Wi-Fi enable devices used in an array of
machine-to-machine (M
2 M) applications. B&B delivers all of the necessary
RF technology networking stacks and advanced security features in a
compact, single-board package, reducing integration costs for OEMs and
providing for a quick time to market.
Big Performance in Small and ruggedized Package
The AirborneM
2 M series delivers the industry’s most rugged, highly
integrated, embedded wireless access point Wi-Fi module solution
AirborneM
2 M modules meet extended operating temperature and shock
vibration specifications of the most demanding M 2 M applications.
Utilizing a 32bit ARM9 processor and the high-performance Atheros
AR6203 802.11 radio, the new AirborneM
2 M modules deliver increased
transmit power and receive sensitivity, contributing to superior range
performance.
Speedlink ™ roaming
The new AirborneM 2 M Speed Link roaming feature provides enhanced
connection reliability, enabling OEM devices to roam freely within a
wireless network without loss of data or connection.
Flexible & easy to integrate
AirborneM
2 M incorporates support for both wireless access point and
serial to Wi-Fi communications. Utilizing AirborneM 2 M Port Flex capability,
OEMs may configure via software any combination of UART, SPI, Ethernet,
GPIO and 802.11 interfaces. Each individual port can be independently
configured.
• Quick time to market and reduced integration costs
• 802.11a/b/g/n Wi-Fi radio (2.4 GHz, 5 GHz)
• AirborneM
2 M Power Save firmware reduces power consumption
and extends battery life in mobile devices
• Extended operating temperature Range (-40°C to +85°C) and
environmental specifications
• AirborneM 2 M Speed Link roaming provides enhanced connection
reliability
• AirborneM
2 M PortFlex capability enables any combination of
communication ports (UART, SPI, GPIO, Ethernet and 802.11
interfaces)
• FCC Part 15 Class B Sub C Modular Approval minimizes regulatory
requirements
• Backwards compatible with previous generations of AirborneM 2 M
embedded modules
produCt FEaturEs
ordErIng InFormatIon
Model nuMBer deSCriPtion
APMN-Q551
802.11a/b/g/n, 10/100 Industrial wireless access point/
router/client: UART, SPI and RS-232/422/485 wired interfaces
WLNN-EK-DP551 Design and Development Kit
The AirborneM 2 M modules are footprint and pin-compatible with their
predecessors. Our commitment to maintaining Hardware and software
compatibility assures OEMs of a simple, future-proof migration path even as
wireless technology evolves.
enterprise Class Security
Security protocols are important to mission critical wireless M
2 M
applications. The AirborneM 2 M ™ Access Point multi-layer security approach
addresses the requirements of Enterprise-class networks and corporate IT
departments. These advanced security features include wireless security
(802.11i/WAP2 enterprise), authentication security using WPA2 (AES-CCMP)
and device security (multi-layered encryption). The AirborneM
2 M ™ Access
Point includes a fully functional DHCP server to provide unique addresses
for each authenticated client. Up to 10 clients can be supported on the local
Wi-Fi network.
aIrBornEm 2 m EmBEddEd dual Band
aCCEss poInt modulE or ClIEnt
802.11a/B/g/n (2.4 ghz, 5 ghz)
aCCEssorIEs
ACH2-DBAT-DP002 - 2 dBi portable (Rubber duck) 2.4/5 GHz antenna
ACH2-DBAT-DP003 - 3.8/5.5 dBi portable (Rubber duck) 2.4 GHz, 5 GHz antenna
World-wide.
Check with your local distributor for availability and options.
APMN-Q551 Series_3713ds
