International Office: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA 815-433-5100 Fax 433-5104
European Office: Westlink Commercial Park Oranmore Co. Galway Ireland +353 91 792444 Fax +353 91 792445
18 Port managed Industrial
ethernet switches with sFP
gigabit Ports
EIR618-2SFP-T
sPecIFIcAtIons
technology
IEEE Standards
802.3 10Base-T Ethernet, 802.3u 100Base-TX and
100Base-FX Fast Ethernet, 802.3x Flow Control and
Back Pressure, 802.1d Spanning Tree, 802.1w Rapid
Spanning Tree, 802.1p Class of Service, 802.1Q VLAN
Tag, 802.3ad Port Trunk with LACP, 802.1x RADIUS,
802.3ab 1000BaseT, 802.3z Gigabit fiber
Processing Type
Store and Forward
Flow Control
Flow control on full duplex, Back Pressure on half
duplex
MAC Address Table Size 8 KB
Memory
4MB Flash ROM, 32MB DRAM
Protocol
CSMA/CD
Management
SNMP v1, v2c, v3, Web GUI, TELNET, CLI, Menu Driven
Interface
Management Security
Up to 10 IP addresses can have permission to manage
the switch. 802.1x (RADIUS) Authentication
Transfer Rate
14,880 bps for 10Base-T Ethernet ports, 148,800 for
100Base-TX/FX Fast Ethernet ports
1,488,000 bps for Gigabit Fiber Ethernet ports
Packet throughput ability 10.7 Mbps @ 64 bytes
X-Ring
2 ports for X-Ring provide redundant backup with a
recovery time below 300 MS.
Packet Filter
4 Selection Rules to filter combinations of Broadcast ,
Multicast, Unicast, and Unknown packets.
VLAN
Port based and Tag. Up to 256 VLAN groups. GVRP (256
Groups)
Port Trunk
LACP Port Trunk. 4 trunk groups / maximum of 4 trunk
members.
Class of Service
4 priority queues per port
Quality of Service
Port based, Tag based, or IPv4 Type of Service, IPv6
Different Service
IGMP
IGMP Snooping v1, v2, and v3. 256 multicast groups
and IGMP query
Clock Synchronization
SNTP
Management Security
IP Address, 802.1x RADIUS
Port Security
Static MAC (100 entries) / MAC Filter (100 entries)
Port Mirror
TX packet only, RX packet only, or TX and RX packet
Firmware Update
TFTP, TFTP backup and restore
DHCP
DHCP Client / DHCP Server
Bandwidth Control
Ingress packet filter and Egress packet limit
interFace
LAN/WAN Ports
16 RJ45 10/100TX, 2 Combo RJ45 10/100/1000 or SFP
ports (RJ45 ports disabled when SFP installed)
Console Port
RS-232 RJ45 (DB9 to RJ45 adapter cable included)
Port Indicators (each
port)
10/100: Link/Activity (Green), Full-duplex/Collision
(Yellow), Giga Copper: Link/Activity (Green), Speed
(1000Mbps Green), SFP: Link/Activity (Green)
System Indicators
Green LEDs for Power, Power 1, Power 2, and Master.
Orange LED for Fault.
Power
Input Voltage
12 to 48 VDC, dual source
Current Consumption
1.1 A max.
Input Connection
Terminal Block
Relay Alarm
1A @ 24VDC
enVironMental
Operating Temperature
-40 to 167°F (-40 to 75°C)
Storage Temperature
-40 to 185°F (-40 to 85°C)
Operating Humidity
0 to 95% Non-condensing
MTBF
243301 hours
Mechanical
Enclosure
IP30 DIN mount metal case
Mount
35 mm DIN or Panel
Dimensions
7.4 x 10.7 x 16.3 cm (2.9 x 4.2 x 6.4 in)
regulatory aPProVals
EMI
FCC Class A
EN6100-4-2, -4-3, -4-4,
EN6100-4-5, -4-6
Safety
EN60950
Free Fall
IEC60068-2-32
Shock
IEC60068-2-27
Vibration
IEC60068-2-6
