B&B Electronics USB2ARC5M - Datasheet - Manual

USB2ARC5M-3413 - 1/1
Model USB2ARC5M
USB 2.0 Active Repeater Cable
Overview
The USB 2.0 Active Repeater Cable acts as a single port hub, which means that multiple cables can be cascaded (up
to 5) to increase the distance between your computer and USB devices. It can extend the distance of a USB device up
to 25 meters.
Features

Cascades to extend distances up to 25 meters between the USB device and the computer

Regenerates the USB signal for maximum reliability and performance over extended distances

Connects to USB device or second active repeater cable

Maximum transfer rate up to 480 Mbps

Supports USB 2.0, 1.1 and 1.0
Specifications
Cable Length: 5 meters
Connectors: Downstream connector (Type A female)
Upstream connector (Type A male)
Data Rate: Up to 480 Mbps (USB 2.0)
Also supports High Speed 12 Mbps and Low Speed 1.5 Mbps
Power: Bus powered
Operating
Temperature:
0~70°C
Storage
Temperature:
-10~80°C
