BENEFITS
Industrial Media Converter
• Compact Size, Smaller Footprint
• Converts 10/100BaseTX to 100BaseFX
•
High Reliability/Availability
• Extended Environmental Specifi cations
• Ruggedized DIN-Rail Enclosure
•
High Performance
• High MTBF >2M Hours (measured)
Ease of Use
• Plug & Play Operation
• RJ-45 Auto Sensing 10/100BaseTX Port
• RJ-45 Port Auto Senses Duplex,
Speed, and Cable Type
• Compact DIN-Rail Package
Increased Performance
• Full Wire Speed Capable
• 100BaseFX Fiber Uplink
• Full Duplex Capable
• Eliminates Network Collisions
• Increases Network Determinism
• N-View Port Viewing Option
302MC-N SPECIFICATIONS
Case dimensions
Height: 3.0" (7.62 cm)
Width: 2.0" (5.08 cm)
Depth: 3.17" (8.052 cm)
Weight: 0.75 lbs (0.3 kg)
Electrical
Input Voltage: 10-30 VDC
Input Current: 250 mA@24V
Inrush: 9.5Amp/0.9ms@24V
Environmental
Operating Temperature: -20 o C to 70 o C
Storage Temperature: -40 o C to 85 o C
Operating Humidity: 10% to 95%
(Non Condensing)
Operating Altitude: 0 to 10,000 ft.
Shock and Vibration (bulkhead mounting)
Shock: 200g @ 10ms
Vibration/Seismic: 50g, 5-200Hz, Triaxial
Network Media
10BaseT: >Cat3 Cable
100BaseTX: >Cat5 Cable
100BaseFX
Multimode:
50-62.5/125μm
Singlemode: 7-10/125μm
Connectors
10/100BaseTX: One (1) RJ-45 TX Port
100BaseFX: One (1) ST or SC Duplex Port
Recommended Wiring Clearance
Front: 4" (10.16 cm)
Top: 1" (2.54 cm)
Ordering Information
302MC-XX 100BaseFX multimode fi ber
302MC-N-XX with N-View Firmware Option
302MCE-XX-YY 100BaseFX singlemode fi ber
302MCE-N-XX-YY with N-View Firmware Option
Where "XX" is: ST for ST style fi ber connector
SC for SC style fi ber connector
Where "YY" is: 15 for 15km max. fi ber segment length
40 for 40km max. fi ber segment length
80 for 80km max. fi ber segment length
THE INDUSTRIAL NETWORK COMPANY
* Multimode Fiber Optic Cable
** Singlemode Fiber Optic Cable
Fiber Transceiver Characteristics
Fiber Length 2km* 15km** 40km** 80km**
TX Power Min -19dBm -15dBm -5dBm -5dBm
RX Sensitivity Max -32dBm -29dBm -34dBm -34dBm
Wavelength 1310nm 1310nm 1310nm 1550nm
Regulatory Approvals
FCC Part 15 Class A
UL Listed 1604 (US and Canada)
CLASS I, DIV 2, GROUPS A,B,C,D,T4A,
CE: EN61000-6-2,4, EN55011, EN61000-4-2,3,4,5,6
ABS Type Approval for Shipboard Applications
GOST-R Certifi ed
RoHS Compliant
