Four Port industrial usB Hub
UH104
uSB Connectivity where you need it
The UH104 is a compact, Industrial Grade Four Port USB 2.0 Hub. It has
High Retention USB connectors that work with standard USB cables
to ensure a tight connection in high vibration applications – requiring
up to 3.4 lbs-force to disconnect them. It provides true USB 2.0 data
transmission through each port, even during heavy load applications. The
UH104 is a plug-and-play device, meaning that there are no additional
drivers to load.
Bus Power
The hub is powered entirely by your high power USB port, leaving your
installation uncluttered by power cabling. As a bus powered device, it
provides 100 mA of power to downstream peripherals. This is adequate for
most applications.
Mount it anywhere
The compact polycarbonate plastic enclosure comes equipped with
mounting brackets that you can use to secure it to a panel, counter top, or
other flat surface. A standard USB cable is required to connect it to your PC.
industrial Specifications
Industrial EMC specifications make this hub more robust than other office
grade products. See the chart to the right to view the complete list of CE
and FCC certifications.
• High Retention USB Connectors
• 15 kV ESD Protection
• Rugged Panel Mount Case
• Wide Operating Temperature (-40 to 80°C)
• USB 2.0 – High Speed (480 Mbps)
ProduCt Features
ordering inFormation
Model nuMBer deSCriPtion
UH104 4 Port Industrial USB Hub
aCCessories
USBAMBM-3F - 3 ft. (0.9 m) USB Extension Cable
UH104_3713ds
