1
About the IE-MediaChassis/2 (AC)
The IE-MediaChassis/2 (AC) is a stand-alone chassis for use with iMcV modules. As
an unmanaged chassis, the IE-MediaChassis/2 (AC) supports two single-wide or one
dual-wide iMcV module. All iMcV modules, with the exception of the SNMP
management card, will function properly in this chassis.
The IE-MediaChassis/2 (AC) contains an internal AC power supply.
The iMediaChassis/2 (AC) includes a temperature triggered fan. When the internal
temperature of the chassis reaches 86° F (30° C) the fan is activated. As the
temperature increases the fan drive duty cycle adjusts to increase the fan speed. You
can test the fan operation by depressing the fan test switch on the back of the chassis.
Installing the IE-MediaChassis/2 (AC)
Use the IE-MediaChassis/2 (AC) as a table-top chassis, mount in a rack mount shelf,
or mount it to a wall surface (brackets are not required).
1. Install the IE-MediaChassis/2 (AC) by placing it on a flat surface.
2. If mounting on a Rackmount shelf, align screw holes and secure with
screws.
