The compact IE-MiniFiberLinX-II provides point-to-point fiber optic
connections with a unique management tool to monitor the entire link
between two locations. IE-MiniFiberLinX-II CPE for fiber optic networks
allows service providers to deliver “triple-play” voice, video and data
services to customer premises.
As a copper-to-fiber converter, the IE-MiniFiberLinX-II supports
multiple fiber types including multi-mode, single-mode, single-strand
fiber (SSF), and Course Wavelength Division Multiplexing (CWDM)
functionality to increase the capacity of existing fiber. As a remote, CPE
device, it can be connected via the fiber segment to an iMcV-FiberLinX-
II Host module to support Host/Remote management.
Equipped with one 100 Mbps fiber data port, one 10/100 twisted pair
port for data and management, as well as an auxiliary port designed to
function as a serial port (when used with the included adapter), the IE-
MiniFiberLinX-II also offers multiple powering options: AC power (with
included adapter), DC (through a 4-terminal power block), as well as
Power over Ethernet, acting as a Powered Device (PD) to draw power
when connected to 802.3af compliant Power Sourcing Equipment
(PSE). Telco versions that support -48 VDC are also available.
Combining copper-to-fiber conversion, extended temperature
performance, plug-and-play operation, miniature size and multiple
power options, the IE-MiniFiberLinX-II is one of the most versatile fiber
optic CPE devices available.
• Loopback troubleshooting
• SNMP Manageable
• Power options: AC, DC and 802.3af Power over Ethernet (PoE)
• Bi-directional Bandwidth control
• MTU: Supports over-sized packets up to 1916
• Supports passive 802.3ah OAM (Operation, Administration
& Management
product FEaturEs
ordErIng InFormatIon
Model
nuMBer
FiBer
FiBer
Ports range
ethernet
Ports
ethernet
ConneCtor
ie-MiniFiberlinx-ii **
856-19717
MM850-ST 1 2 km 1 RJ45
856-19718 MM850-SC 1 2 km 1 RJ45
856-19722 MM1300-ST 1 5 km 1 RJ45
856-19723 MM1300-SC 1 5 km 1 RJ45
856-19724 ST1310/PLUS-SC 1 40 km 1 RJ45
856-19725 SM1310/PLUS-SC 1 40 km 1 RJ45
856-19726 ST1310/LONG-SC 1 80 km 1 RJ45
856-19727 SM1310/LONG-SC 1 80 km 1 RJ45
856-19730 SM1550/LONG-SC 1 80 km 1 RJ45
856-19728 SM1550/XLONG-SC 1 100 km 1 RJ45
single strand FiBer *
856-19750 SSFX-MM1310-SC 1 2 km 1 RJ45
856-19751 SSFX-MM1550-SC 1 2 km 1 RJ45
856-19752 SSFX-SM1310-SC 1 20 km 1 RJ45
856-19753 SSFX-SM1550-SC 1 20 km 1 RJ45
856-19754
SSFX-SM1310/
PLUS-SC
1 40 km 1 RJ45
856-19755
SSFX-SM1550/
PLUS-SC
1 40 km 1 RJ45
856-19756
SSFX-SM1310/
LONG-SC
1 60 km 1 RJ45
856-19757
SSFX-SM1550/
LONG-SC
1 60 km 1 RJ45
10/100 mbps managed optical demarcation
compact cpE device
IE-MiniFiberLinX-II
10/100 mbps managed optical
demarcation compact cpE device
IE-MiniFiberLinX-II
* These products have single-strand fiber technology. Deploy in pairs or connect another compatible
B&B IMC LLC single-strand fiber product.
** For a complete list of modules without an AC Adapter, contact IMC Networks
IE-MiniFiberLinX-II also available in CWDM Fiber.
Call for details.
accEssorIEs
806-39105 - DIN Rail Clip
806-39638 - Double-USB Power Cable, 36”/.9m
806-39650 - 12”/.3m Barrel-Connector Power Cable
806-39753 - IE-Power/5V Module, AC to DC DIN Rail Power Adapter
i View 2
DEVICE MANAGEMENT APPLICATION
iView: Windows 2000/XP/Vista/Win7
IE MiniFiberLinX-II_0614ds
