Pc card ethernet media converters
www
.
bb
-
elec
.
com
|
pc card Ethernet media converters
McPC Series 100, 10/100 & Gigabit
McPC Series Media Converters are ideal for Fiber-to-the-Desktop
(FTTD) applications and for companies with frequent workstation
moves and changes. Installing inside a PC or workstation, and plugging
into an adjacent network interface card (NIC), these compact units
eliminate the need to place Media Converters on top of desks or
computers, reducing clutter of cords and adapters at the workspace.
the McPC series includes:
• 100 Mbps Fast Ethernet (TX/FX) - Designed to connect to NIC
cards running at Fast Ethernet speeds
• 10/100 Mbps - A media converter that auto-senses the
connected device’s rate (10 Mbps or 100 Mbps) and duplex
mode (Half-Duplex/Full-Duplex)
• 1000 Mbps Gigabit Ethernet (TX/SX or /LX) - Converts 1000
Mbps over copper to 1000 Mbps over fiber. Ideal for bringing
Gigabit speed connectivity to the desktop
McPC converters accommodate crossover or pass through cables,
with either a pushbutton MDI/MDIX switch or AutoCross, a feature
which automatically selects the correct operating mode. Units also
feature handy status LEDS to assist in network diagnostics and
troubleshooting. In addition, McPC TX/FX and McPC 10/100 include
troubleshooting features that make it easy to isolate fiber breaks.
product FEaturEs
* These products have single-strand fiber technology. Deploy in pairs or connect another compatible
B&B IMC LLC single-strand fiber product.
ordErIng InFormatIon
Model
nuMBer
FiBer
FiBer
Ports range
ethernet
Ports
ethernet
ConneCtor
McPC tx/Fx 100 Mbps isa
855-13127 MM1300-ST
1
5 km
1
RJ45
855-13128 MM1300-SC
1
5 km
1
RJ45
855-13328 SM1310/PLUS-SC
1
40 km
1
RJ45
McPC tx/Fx 100 Mbps PCi
855-12127 MM1300-ST
1
5 km
1
RJ45
855-12128 MM1300-SC
1
5 km
1
RJ45
855-12328 SM1310/PLUS-SC
1
40 km
1
RJ45
•
Easily installs inside a desktop PC
•
No configuration required, connects to existing NIC card
•
No drivers to install
•
Available in an ISA or PCI style bracket
ordErIng InFormatIon
Model
nuMBer
FiBer
FiBer
Ports range
ethernet
Ports
ethernet
ConneCtor
McPC 10/100 Mbps isa
855-13260 MM850-ST
1
2 km
1
RJ45
855-13261 MM850-SC
1
2 km
1
RJ45
855-13263 MM1300-SC
1
5 km
1
RJ45
McPC 10/100 Mbps PCi
855-12260 MM850-ST
1
2 km
1
RJ45
855-12261 MM850-SC
1
2 km
1
RJ45
855-12263 MM1300-SC
1
5 km
1
RJ45
ordErIng InFormatIon
Model
nuMBer
FiBer
FiBer
Ports range
ethernet
Ports
ethernet
ConneCtor
McPC-gigabit 1.25 gbps PCi
855-12900 MM850-SC
1
220/550 m 1
RJ45
855-12901 SM1310-SC
1
15 km
1
RJ45
855-12902 SM1310/PLUS-SC
1
40 km
1
RJ45
855-12903 SM1550/LONG-SC
1
80 km
1
RJ45
single-strand FiBer*
855-12904 SSLX-SM1310-SC
1
15 km
1
RJ45
855-12905 SSLX-SM1550-SC
1
15 km
1
RJ45
855-12906 SSLX-SM1310/
PLUS-SC
1
40 km
1
RJ45
855-12907 SSLX-SM1550/
PLUS-SC
1
40 km
1
RJ45
High Bandwidth for
National Archives
Industry: Enterprise IT
Product: Mc PC Multi-mode Fiber
Media Converters
www.bb-elec.com/
Archives
Carrier data charges
may apply.
In thE FIEld
accEssorIEs
806-39230 - SATA Cable for McPC
