12

AM Series Small Junction Boxes:
Lift-Off Screw Cover

A P P L I C A T I O N

• Designed for use as electrical junction boxes, terminal wiring boxes, instrumentation

housings and electrical control enclosures

• Especially well suited for high temperature or corrosive environments
• Protects from dirt, dust, oil and water
• For use with industrial control equipment in ordinary locations

S T A N D A R D S

• Construction meets NEMA/EEMAC Type 4, 4X, 12 specifications
• UL 508 listed, Type 1, 2, 3, 3R, 4, 4X, 12, 13
• CSA certified LR 89590 for use with industrial control equipment CSA Enc. 1, 2, 3, 4, 4X, 12, 13

C O N S T R U C T I O N

• Rugged, molded fiberglass reinforced polyester construction with reinforced corners
• Two standard sizes: 7" x 4" x 3" and 9" x 4" x 3"
• 304 Stainless steel captive cover screws and mounting feet
• “Tongue and groove” type closed-cell neoprene gasket
• Threaded inserts for optional aluminum back panel
• UV stabilized for outdoor use

A C C E S S O R I E S

• Optional aluminum back panels

M O D I F I C A T I O N S

• Custom holes and cutouts
• Custom size polycarbonate viewing windows
• Molded-in color matches

•EMI/RFI shielding

• Factory-supplied silk screening
