Serial i/o cards

background image

Serial I/O

CF Card

Serial I/O

PC Card

Dual

Serial I/O

PC Card

Quad

Serial I/O

PC Card

SKU#

Standard: SL2700-096

Ruggedized: SL2703-138

Standard: SL0700-004

Ruggedized: SL0707-078

Standard: SL0703-081

Ruggedized: SL0723-116

Ruggedized: SL0751-161

Number of RS-232

Ports

1

1

2

4

Plug-in Card

Dimensions

1.43 x 1.69 x 0.13 in.

(36.4 x 42.8 x 3.3 mm)

3.37 x 2.13 x 0.20 in.

(85.6 x 54 x 5 mm)

3.37 x 2.13 x 0.20 in.

(85.6 x 54 x 5 mm)

3.37 x 2.13 x 0.20 in.

(85.6 x 54 x 5 mm)

Cable Length

Removable: 12 in. (31 cm)

Non-removable: 17 in. (43 cm)

Removable: 12 in. (31 cm)

Non-removable: 17 in. (43 cm)

Removable: 12 in. (31 cm)

Non-removable: 17 in. (43 cm)

Non-removable: 24 in. (61 cm)

Connector

9-pin D Shell male

Operating

Temperature

N/A

N/A

0 to 70° C

0 to 55° C

Storage

Temperature

N/A

N/A

-20 to +100° C

N/A

Relative Humidity

N/A

N/A

10% to 90% non-condensing

10% to 90% non-condensing

Power Consumption

(3.3 V)

Standby: 2.4 mA (8 mW)

Typical: 8 mA (26 mW)

N/A

N/A

N/A

Power Consumption

(5 V)

Standby: 4.3 mA (22 mW)

Typical: 13 mA (65 mW)

Standby: 5 mA (25 mW)

Typical: 13 mA (65 mW)

Minimum: 5 mA (25 mW)

Typical:

1 port: 13 mA (65 mW)

2 ports: 21 mA (105 mW)

Maximum:

1 port: 16 mA (96 mW)

2 ports: 27 mA (135 mW)

Compatible Systems: 3V, 5.5V

Minimum: 5.8 mA (29 mW)

Typical:

1 port: 19.2 mA (96 mW)

2 ports: 32.1 mA (160.5 mW)

3 ports: 44.3 mA (221.5 mW)

4 ports: 55.6 mA (278 mW)

Maximum:

1 port: 19.5 mA (97.5 mW)

2 ports: 32.3 mA (161.5 mW)

3 ports: 44.5 mA (222.5 mW)

4 ports: 55.8 mA (279 mW)

Interface Standard*

CompactFlash Type I

(with adapter, also works in PC

Card slot)

PC Card (PCMCIA) Type II,

JEIDA 4.1

PC Card (PCMCIA) Type II,

JEIDA 4.1

PC Card (PCMCIA) Type II,

JEIDA 4.1

Maximum Baud

Rate

921 kbps

921 kbps

921 kbps

115 kbps

Serial

Communications

Asynchronous RS-232, fully RS-232 compliant

Custom options for RS-422, RS-485, etc. for OEMs for minimum 1,000 units

Serial I/O Cards
