516TX Industrial Ethernet Switch Ordering Information
516TX Sixteen 10/100BaseTX Ports
516TX-N 516TX with N-View
516TX-A 516TX with N-View and Advanced Management Features
516TX-A Specifi cations
Switch Properties
Number of MAC Addresses: 4,000
Aging Time:
300 s
Latency Typical: 2.1 μs
Backplane Speed: 2.6Gb/s
Switching Method: Store & Forward
Case Dimensions
Height:
2.3" (5.8cm)
Width: 7.4" (18.8cm)
Depth: 3.5" (8.8cm)
Weight: 2.2 lbs (1.0kg)
Din-Rail: 35mm
Electrical
Redundant Input Voltage:
10-30 VDC
Input Current: 400 mA@24V
Inrush: 7.0Amp/0.8ms@24V
Environmental
Operating Temp:
-40 o C to 85 o C
Storage Temp: -40 o C to 85 o C
Operating Humidity: 10% to 95%
(Non Condensing)
Operating Altitude: 0 to 10,000 ft.
Shock and Vibration (bulkhead mounted)
Shock:
200g @ 10ms
Vibration/Seismic: 50g, 5-200Hz, Triaxia
Reliability
MTBF:
>1 Million Hours
Network Media
10BaseT:
>Cat3 Cable
100BaseTX: >Cat5 Cable
Connectors
10/100BaseTX: Sixteen (16) RJ-45 Copper Ports
Serial Confi guration Port
Com Parameters: 9600,n,8,1
Recommended Wiring Clearance
Front:
2" (5.08 cm)
Side: 1" (2.54 cm)
THE INDUSTRIAL NETWORK COMPANY
Regulatory Approvals
FCC/CE (CFR 47, Part 15, Subpart B, Class A)
EMC Dir 89/336/EEC, EN 50204, EN 55011
EN61000-4-2/3/4/5/6/8/11, EN61000-6-2/4
ANSI C63.4, ICES-003
UL /cUL: Class I, Div 2, Groups A, B, C, D and T4A
UL 508 and UL 1604
CAN/CSA-C22.2 No.213, ATEX II 3 G Ex nA
ABS Type Approval for Shipboard Applications
GOST-R Certifi ed, RoHS Compliant
Designed to comply with:
IEEE 1613 for Electric Utility Substations
NEMA TS1/TS2 for Traffi c Control
REV 090804
