multi-port, 10/100 mbps switching
standalone media converter
AccessConverter
multi-port, 10/100 mbps switching
standalone media converter
AccessConverter
Terminating a fiber run while using various local, copper-based
devices such as PCs, printers, VoIP, etc. is essential for the success of
Fiber-to-the Business, Curb and other FTTx projects. Remote locations
have similar configuration demands. Connecting the multiple copper
devices to the fiber, however, typically requires the use of both a media
converter and a switch— two pieces of equipment to purchase and
two pieces of equipment to monitor and maintain. The AccessConverter
streamlines FTTx projects as well as the connection of remote locations
as a multi-port, switching media converter.
Best of all, one compact AccessConverter module reduces the amount
of required equipment while providing all the features of a switch (store
and forward switching mechanics, MAC address learning, protection
against broadcast storms, flow control, etc.) and performing the
electrical-to-optical conversion. In addition, the unit’s small size and
wall-mount bracket (included) allow you to install AccessConverter
virtually anywhere, including inside a network interface device (NID).
requiring no configuration, the accessConverter offers plug-and-
play operation:
•
Each copper port auto-senses the connected device’s speed
and duplex mode (10 Mbps or 100 Mbps and HDX or FDX)
and includes AutoCross, a feature which automatically selects
between a crossover workstation (MDIX) or pass-through (MDI)
connection depending on the connected device
•
The fiber port always operates at 100 Mbps FDX, and supports
distances up to 80 km; single-strand fiber versions are available.
• Low cost, high flexibility — same small unit performs media conversion
and switching functions
• Offers three downlink connections
• Compact size allows for flexible installation configurations
• Unmanaged
product FEaturEs
ordErIng InFormatIon
Model
nuMBer
FiBer
FiBer
Ports range
ethernet
Ports
ethernet
ConneCtor
accessConverter
852-10140
100 m
4
RJ45
852-10150
MM850-ST
1
2 km
3
RJ45
852-10151
MM850-SC
1
2 km
3
RJ45
852-10141
MM1300-ST
1
5 km
3
RJ45
852-10142
MM1300-SC
1
5 km
3
RJ45
852-10141-MT MM1300-MT
1
5 km
3
RJ45
852-10143
SM1310/PLUS-ST 1
40 km
3
RJ45
852-10144
SM1310/PLUS-SC 1
40 km
3
RJ45
852-10145
SM1310/LONG-ST 1
80 km
3
RJ45
852-10146
SM1310/LONG-SC 1
80 km
3
RJ45
852-10147
SM1550/LONG-SC 1
80 km
3
RJ45
single-strand FiBer *
852-10153
SSFX-SM1310-SC 1
20 km
3
RJ45
852-10154
SSFX-SM1550-SC 1
20 km
3
RJ45
852-10155
SSFX-SM1310/
PLUS-SC
1
40 km
3
RJ45
852-10156
SSFX-SM1550/
PLUS-SC
1
40 km
3
RJ45
852-10157
SSFX-SM1310/
LONG-SC
1
60 km
3
RJ45
852-10158
SSFX-SM1550/
LONG-SC
1
60 km
3
RJ45
* These products have single-strand fiber technology. Deploy in pairs or connect another compatible
B&B IMC LLC single-strand fiber product.
