Features

www.advantech.com/products

Online Download

UNO-1019

Marvell

®

XScale PXA-255 200 MHz Processor

64 MB SDRAM on board, 32 MB Flash
2 x RS-232, 2 x RS-232/422/485 Serial Ports
Dual 10/100 Mbps Ethernet
1 x CompactFlash

®

for DATA storage

Windows

®

CE 5.0 Ready Platform and optional uClinux OS support

Included Advantech DaigAnywhere for Easy Configuration
DIN-rail and Wallmounting Options
Onboard system & I/O LED indicators
Supports Microsoft .NET compact framework 2.0 (WinCE 5.0 only)
Fanless and no internal cabling design











Introduction

Advantech’s UNO-1019 is a RISC-grade embedded platform that offers 2 LANs, 4 serial ports and 4 Digital Inputs/Outputs and a CompactFlash slot. UNO-1019 also comes with
Windows CE 4.2/5.0 OS, offering a pre-built image onboard. Additionally, UNO-1019 operates under 0 ~ 70° C, and its small size and lightweight design allows it to be installed in
tight industrial environments. UNO-1019 is an excellent communication gateway for converting communication protocosl, I/O control, and data storage in the industrial field.

Specifications

General

Certifications

CE, FCC Class A

Dimensions (W x H x D) 46 x 162 x 126 mm (1.8" x 6.4" x 5")
Enclosure

ABS+PC with solid mounting hardware

Mounting

DIN-rail, wallmount

Power Consumption

8.5 W

Power Input

10 ~ 30 V

DC

(13 W), AT

Weight

400 g

System Hardware

CPU

32-bit Marvell XScale PXA255 200 MHz

Memory

Onboard 64 MB SDRAM

Indicators

Power, Serial (Tx, Rx), 3 x User Defined LEDs

Storage

Onboard 16 or 32 MB Flash Memory
SSD: 1 x external type I/II CompactFlash

®

slot

Other

Realtime clock, Watchdog timer

System Software

Operating System

Windows CE 4.2/5.0
(Pre-installed on onboard flash memory)

Remote Display

Advantech DiagAnywhere (optional)

Communications

Serial Ports

2 x RS-232, 2 x RS-232/422/485 with DB9 connectors,
Automatic RS-485 data flow control

Serial Port Speed

RS-232: 300 ~ 115.2 kbps
RS-422/485: 300 ~ 115.2 kbps

LAN

2 x 10/100 Base-T RJ-45 ports










Digital Input/Digital Output

Digital Inputs

2 x Digital Inputs
Dry contact

Logic level 0: Open

Logic level 1: Close

Wet contact

Logic level 0: +3 V max

Logic level 1: +10 V

DC

to 30 V

DC

Digital Outputs

2 x Digital Outputs
Open Collect to 30 V
200 mA max Load, power dissipation 450 mW

Environment

Operating Temperature 0 ~ 70° C (32 ~ 158° F)
Storage Temperature -20 ~ 80° C (-4 ~ 176° F)
Operating Humidity

20 ~ 95% (non-condensing)

Storage Humidity

0 ~ 95% (non-condensing)

Ordering Information

UNO-1019ACE-A1E

Marvell XScale UNO w/2 x LAN, 4 x COM, Windows
CE 4.2, onboard 16 MB Flash Memory

UNO-1019ACE-A2E

Marvell XScale UNO w/2 x LAN, 4 x COM, Windows
CE 5.0, onboard 32 MB Flash Memory

PCLS-DIAGAW10

Advantech Remote Monitoring & Diagnosis Utility




Marvell

®

XScale UNO with 2 x LAN,

4 x COM, 4 x DI/O
