X Input
Input voltage AC 100-120/220-240V (switchable), 47...63Hz
(AC 85...132V / AC 184...264V, DC 220...375V)
Input current <1.6A (@ AC 100V, 72W P
out
)
<0.8A (@ AC 220V, 72W P
out
)
External fusing Not required, unit provides internal fuse
(T3A15H, not accessible)
Transient immunity Transient resistance acc. to VDE 0160 / W2
(750V / 1.3ms), over entire load range
Hold-up time
(see diagram below) >25ms @ AC 100V, 24V / 3A
>27ms @ AC 196V, 24V / 3A
>40ms @ AC 230V, 24V / 3A
X Efficiency, Reliability
Efficiency
Losses
typ. 89% (AC 230V, 24V / 3A)
(see also diagram below)
typ. 8.7W
(AC 230V, 24V / 3A)
MTBF (Reliability) appr. 600.000h acc. Siemensnorm SN29500
(24V / 3A, AC 230V, T
amb
= +40°C)
Prior to shipment, every unit undergoes the following tests in order to
isolate any defective units which might suffer an early failure:
• Run-in / burn-in (Full load, T
amb
= +60°C, on/off cycle)
• Functional test (100%)
X Construction, Mechanics, Installation
Robust plastic housing (US Patent No. D442, 923S), fine ventilation grid
on three housing sides to keep out small parts (e.g. screws), IP20
Dimensions and weight
• W x H x D
• Weight
45mm x 75mm x 91mm (+ DIN rail)
Depth incl. terminals: 91mm (+ DIN rail)
260g
Mounting orientation , or (cf. ’Output’)
Ventilation/Cooling
• Free space f. cooling Normal convection, no fan required
recom’d.: 25mm on sides with ventilation grid
Easy snap-on mounting onto the DIN Rail (TS35/7,5 or TS35/15).
Unit sits safely and firmly on the rail; no tools required even to remove
Connection by Spring Clamp terminals; uniformly firm hold,
vibration-resistant and maintenance-free:
2 terminals per output
Connector size range
• flexible cable
• solid cable
• Wire strip length
0.3-2.5mm 2 (28-12 AWG)
0.3-4mm 2 (28-12 AWG)
Ferrules admissible
6mm (0.24in) recommended
X Diagrams
0
4
8
12
16
20
24
28
32
0 0,5 1 1,5 2 2,5 3 3,5 4 4,5 5
Output current Iout [A]
O
utput v
ol
tage Vout [V
]
Vin = AC 115/230V
0
20
40
60
80
100
120
140
160
80 120 160 200 240 280
Input voltage VACin [V]
H
old-up time [ms
]
Pout=72W, typ.
Pout=72W, min.
Pout=36W, typ.
Pout=36W, min.
50
55
60
65
70
75
80
85
90
95
0,5 1 1,5 2 2,5 3
Output current Iout [A]
E
ffi
ci
ency [
%
]
230V ACin
115V ACin
0
10
20
30
40
50
60
70
80
-10 0 10 20 30 40 50 60 70
Ambient temperature [°C]
Out
put
power [
W
]
Output characteristic V
out
/I
out
(min.)
Efficiency Hold-up time with ACin
(@ V
out
= 24.5V, typ.) (@ V
out
= 24.5V, typ. + min.)
Derating
of output power
a
b
A
Mounting
85-132 V ACin A-a A-a A-b
185-264 V ACin A-a A-a A-b
220-375 V DCin A-a A-a A-b
switch pos.
115V
switch pos.
230V
Vout range
X Output
Output voltage
• preset DC 24-28V adj. by front panel potentiometer;
24.5V ±0.5% at rated load
Voltage regulation stat. <1% V
out
dyn. < ±2% V
out
over all
Ripple/Noise <50mV
PP
(20MHz bandw., 50 Ω measurem.)
Overvoltage prot. (OVP) <40V
Rated continuous
loading up to 3A @ 24V /2.6A @ 28V (convection cooling)
depending on built-in orientation, V
in
and T
amb
;
for details see derating diagram below
Overload behaviour PULS Overload Design™: No switch-off at
overload/short-circuit, instead: up to 1.5
⋅ I
rated.
So you need no oversizing to start awkward
loads.
Protection Unit is protected against (also permanent) short-
circuit, overload and open-circuit.
Derating see diagram below
Power back immunity max. 35V
Operating indicator Green LED
X Environmental Data, EMC, Safety
Ambient temperature range (measured 25mm below unit)
• storage/transport
• operation
-25°C ... +85°C
-10°C ... +70°C (for derating see diagram below)
Humidity max. 95% (without condensation)
Electromagnetic
emissions (EME) EN 61000-6-3 (includes EN 61000-6-4)
Class B (EN 55011, EN 55022)
Electromagnetic
immunity (EMI) EN 61000-6-2 (includes EN 61000-6-1)
Safe low voltage:
Prot. class/degree: SELV (EN 60950, VDE0100/T.410), PELV (EN 50178)
Class I (EN 60950) / IP20 (EN 60529)
The PSU complies with all major safety approvals for EU
(EN 60 950, EN 60204-1, EN 50178), USA (UL 60950, UL508 LISTED),
Canada (CAN/CSA-C22.2 No 60950 [CUR], CAN/CSA-C22.2 No. 14 [CUL]),
CB Scheme (IEC 60950). NEC Class 2 Power Supply
Design details – for your advantage:
• All terminals are easy to reach as mounted on the front panel.
• Input and output are strictly apart from each other (input below, out-
put above) and so cannot be mixed up
• Mounting and connection do not require any screwdriver
→ Easy, quick, durable and reliable installation
Technical Data ML70.100
Product information (ML70e100), Rev: 1. December 2004. Unless otherwise stated, specifications are valid for AC 230V input voltage, +25°C ambient temperature, and 5 min. run-in time.
They are subject to change without prior notice..
PULS GmbH, Arabellastraße 15, D-81925 München X Tel: +49.(0)89.9278-244, Fax: +49.(0)89.9278-199, E-Mail: [email protected] X www.puls-power.com
