ABDx-SE-IN54xx
CD with Airborne Management Center
software
5-36 VDC power for terminal block
or a 5 VDC Power Supply (not included)
50 ohm, omni-directional antenna
First Things First...
Before you begin, be sure you have
the following:
Industrial Serial Device Server
Fast, Easy Answers
ABDx-SE-IN54xx
Continuing section 6
Use the Help features of the interface to help you
configure the device. When you are done with
configuring the device, press ‘Commit’ to save the
changes, then ‘Restart’ to restart the device. You
can optionally press ‘Reload’ if you have further
configuration changes to make.
Check Your Setup
If your device is connected and configured correctly, you
will see the following LED Status:
COMM:
GREEN
LINK:
GREEN
POST:
GREEN
POWER:
BLUE
LED
Airborne Device State
POWER
Adapter is not powered.
Adapter is powered
POST
Adapter is not powered.
Adapter failed Power On Self Test (POST) and is not
configured for wireless communication.
Adapter passed POST but is not configured for wireless
network communication.
Adapter passed post and is configured for wireless
communication.
LINK
Adapter is not powered.
(Periodic Blinking) Adapter is searching for a valid net-
work (Access Point) that matches device’s configuration.
Adapter has successfully associated with an Access Point.
COMM
If Power LED is also Off then Adapter is not powered.
If Power LED is On then: No TCP session from WLAN or
Ethernet interface has been established.
A TCP connection to the adapter has been established
from the Wireless or Ethernet interfaces but no traffic has
been detected.
PIN
RS-232 (DTE)
Port 1 & 2
(Default
RS-422/485
1
No Connect
No Connect
2
RxD
RxD+
3
TxD
TxD+
4
No Connect
No Connect
5
GND
GND
6
No Connect
RxD-
7
RTS
No Connect
8
CTS
No Connect
9
No Connect
TxD-
