switching 10/100 mbps media
converter module
McLIM TP-TX/FX
switching 10/100 mbps media
converter module
McLIM TP-TX/FX
Your network is growing and many new access points, workstations,
etc. are required. However, legacy equipment, along with your
existing wiring infrastructure, must work with any new equipment
you implement in your network. When copper-to-fiber conversions
are required, along with advanced troubleshooting features, our
MediaConverter Series is the perfect solution.
MediaConverter Series enables you to easily and cost-effectively
connect one type of media to other dissimilar media or networking
products. This series increases the functionality and extends
the productive life of both your legacy cabling infrastructure and
networking equipment when adding fiber to your network.
product FEaturEs
* These products have single-strand fiber technology. Deploy in pairs or connect another compatible
B&B IMC LLC single-strand fiber product.
ordErIng InFormatIon
Model
nuMBer
FiBer
FiBer
Ports range
ethernet
Ports
ethernet
ConneCtor
McliM tP-tx/Fx
855-12620 MM850-ST
1 220/550 m 1 RJ45
855-12621 MM850-SC 1 220/550 m 1 RJ45
855-12622 MM1300-ST 1 5 km 1 RJ45
855-12623 MM1300-SC 1 5 km 1 RJ45
855-12624 SM1310/PLUS-ST 1 40 km 1 RJ45
855-12625 SM1310/PLUS-SC 1 40 km 1 RJ45
single-strand FiBer *
855-12642 SSFX-SM1310-SC 1 20 km 1 RJ45
855-12643 SSFX-SM1550-SC 1 20 km 1 RJ45
855-12644 SSFX-SM1310/
PLUS-SC
1 40 km 1 RJ45
855-12645 SSFX-SM1550/
PLUS-SC
1 40 km 1 RJ45
• Modular, hot-swappable architecture reduces operational costs
associated with product installations, upgrades and maintenance
• One 10/100 Mbps twisted pair port with and RJ45 connector
• One 100 Mbps fiber port with ST and SC connectors
• Plug-and-play operation
McLIM TP-TX/FX_3713ds
