10 Port managed Industrial ethernet
switches, 3 combo Ports
EIR610-3SFP-T
sPecIFIcAtIons
technology
IEEE Standards
802.3 10Base-T Ethernet, 802.3u 100Base-TX and
100Base-FX Fast Ethernet; 802.3x Flow Control and
Back Pressure, 802.1d Spanning Tree, 802.1w Rapid
Spanning Tree; 802.1p Class of Service, 802.1Q VLAN
Tag, 802.3ad Port Trunk with LACP, 802.1x RADIUS
Processing Type
Store and Forward
Flow Control
Flow control on full duplex, Back Pressure on half
duplex
MAC Address Table Size 8 KB
Memory
4MB Flash ROM, 32MB DRAM
Protocol
CSMA/CD
Management
SNMP v1, v2c, v3, Web GUI, TELNET, CLI, Menu Driven
Interface
Management Security
Up to 10 IP addresses can have permission to manage
the switch. 802.1x (RADIUS) Authentication
Transfer Rate
14,880 bps for 10Base-T Ethernet ports, 148,800 for
100Base-TX/FX Fast Ethernet ports
Packet throughput ability 8.3 Mbps @ 64 bytes
X-Ring
2 ports for X-Ring provide redundant backup with a
recovery time below 300 MS.
Packet Filter
4 Selection Rules to filter combinations of Broadcast ,
Multicast, Unicast, and Unknown packets.
VLAN
Port based and Tag. Up to 256 VLAN groups
Port Trunk
LACP Port Trunk. 4 trunk groups / maximum of 4 trunk
members.
Class of Service
4 priority queues per port
Quality of Service
Port based, Tag based, or IPv4 Type of Service, IPv6
Different Service
IGMP
IGMP Snooping v1, v2, and v3. 256 multicast groups
and IGMP query
Clock Synchronization
SNTP
Management Security
IP Address
Port Mirror
TX packet only, RX packet only, or TX and RX packet
Firmware Update
TFTP, TFTP backup and restore
DHCP
DHCP Client / DHCP Server
Bandwidth Control
Ingress packet filter and Egress packet limit
interFace
LAN/WAN Ports
7 RJ45 10/100TX, 3 Combo RJ45 10/100/1000 or
100/1000 SFP Mini-GBIC Combo
(On Combo ports the RJ45 is disabled when an SFP
module is installed)
Console Port
RS-232 RJ-45 (DB9 to RJ-45 adapter cable included)
Port Indicators (each
port)
10/100: Link/Activity (Green), Full-duplex/Collision
(Yellow); Giga Copper: Link/Activity (Green), Speed
(1000Mbps Green); SFP: Link/Activity (Green)
System Indicators
Green LEDs for Power, Power 1, Power 2, and Master.
Orange LED for Fault.
rFc standards
snMP traP
RFC1215 Trap
Up to 3 Trap Stations
RFC1213 MIBII
Cold Start
RFC1157 SNMP MIB
Port link up
RFC1493 Bridge
Port link down
RFC2674 VLAN MIB
Authentication Failure
RFC1643
Power status
RFC 757
Port Alarm
RSTP MIB
Fault Alarm
Private MIB
X-Ring Change
Power
Input Voltage
12 to 48 VDC, dual source
Current Consumption
0.84 A max.
Input Connection
Terminal Block
Relay Alarm
1A @ 24VDC
enVironMental
Operating Temperature
-40 to 167°F (-40 to 75°C)
Storage Temperature
-40 to 185°F (-40 to 85°C)
Operating Humidity
10 to 95% Non-condensing
MTBF
260818 hours
Mechanical
Enclosure
IP30 DIN mount metal case
Mount
35 mm DIN or Panel
Dimensions
7.4 x 10.7 x 16.3 cm (2.7 x 4.2 x 6.4 in)
regulatory aPProVals
EMI
FCC Class A
EN6100-4-2, -4-3, -4-4,
EN6100-4-5, -4-6
Safety
EN60950
Free Fall
IEC60068-2-32
Shock
IEC60068-2-27
Vibration
IEC60068-2-6
