509FX Industrial Ethernet Switch Ordering Information
509FX-A-XX-S
Eight 10/100BaseTX Ports, One Multimode 100BaseFX Fiber Optic Port
509FXE-A-XX-YY
Eight 10/100BaseTX Ports, One Singlemode 100BaseFX Fiber Optic Port
Where:
A = A for Advanced Management Features,
or N for N-View,and Blank Otherwise, N-View included in -A;
XX = ST or SC, YY = 15, 40 or 80 for singlemode, blank for multimode
S = Standard Temperature Rating -20ºC to 70ºC, Blank for -40ºC to 85ºC
509FX-A Specifi cations
Switch Properties
Number of MAC Addresses:
4,000
Aging Time:
300
s
Latency Typ.:
2.1
μs
Backplane Speed:
2.6Gb/s
Switching Method:
Store & Forward
Case Dimensions
Height:
2.3"
(5.8cm)
Width:
5.5" (13.9cm)
Depth:
3.4" (8.8cm)
Weight:
1.6 lbs (0.8kg)
Din-Rail:
35mm
Electrical
Redundant Input Voltage:
10-30 VDC
Input Current:
260
mA@24V
Inrush:
8.5Amp/0.7ms@24V
Environmental
Operating and Storage Temp:
-20ºC to 70ºC (Standard)
-40ºC
to
85ºC
(Extended)
Operating Humidity:
10% to 95%
(Non
Condensing)
Operating Altitude:
0 to 10,000 ft.
Shock and Vibration (bulkhead mounting)
Shock:
200g @ 10ms
Vibration/Seismic:
50g,
5-200Hz,
Triaxial
Reliability
MTBF:
>2Million
Hours
Network Media
10BaseT:
>Cat3
Cable
100BaseTX
:
>Cat5
Cable
100BaseFX
Multimode:
50-62.5/125μm
Singlemode:
7-10/125μm
Connectors
10/100BaseTX:
Eight (8) RJ-45 Copper Ports
100BaseFX:
One (1) SC or ST Duplex Port
Serial Confi guration Port
Com Parameters:
9600,n,8,1
Recommended Wiring Clearance
Front:
4" (10.16 cm)
Side:
1" (2.54 cm)
Regulatory Approvals
FCC/CE (CFR 47, Part 15, Subpart B, Class A)
EMC Dir 89/336/EEC, EN 50204, EN 55011
EN61000-4-2/3/4/5/6/8/11, EN61000-6-2/4
ANSI C63.4, ICES-003
UL /cUL: Class I, Div 2, Groups A, B, C, D and T4A
UL 508 and UL 1604
CAN/CSA-C22.2 No.213, ATEX II 3 G Ex nA
ABS Type Approval for Shipboard Applications
GOST-R Certifi ed, RoHS Compliant
Designed to comply with:
IEEE 1613 for Electric Utility Substations
NEMA TS1/TS2 for Traffi c Control
REV 090804
Contact Information
N-TRON Corp.
N-TRON Europe GmbH
820 S. University Blvd., Suite 4E
Alte Steinhauserstr 19
Mobile, AL36609USA
6330 Cham / Zg Switzerland
TEL: (251) 342-2164
TEL: +41 41 7406636
FAX: (251) 342-6353
FAX: +41 41 7406637
Website: www.n-tron.com
Email: [email protected]
® 2009 N-TRON, Corp., N-TRON and the N-TRON logo are trademarks of N-TRON, Corp. Product names mentioned herein are for identifi cation purposes only and
may be trademarks and/or registered trademarks of their respective company. Specifi cations subject to change without notice.
The responsibility for the use and application
of N-TRON products rests with the end user. N-TRON makes no warranties as to the fi tness or suitability of any N-TRON product for any specifi c application. N-TRON Corporation
shall not be liable for any damage resulting from the installation, use, or misuse of this product.
Printed in USA.
Fiber Transceiver Characteristics
Fiber Length
2km*
15km**
40km**
80km**
TX Power Min
-19dBm
-15dBm
-5dBm
-5dBm
RX Sensitivity Max
-32dBm
-29dBm
-34dBm
-34dBm
Wavelength
1310nm
1310nm
1310nm
1550nm
* Multimode Fiber Optic Cable
** Singlemode Fiber Optic Cable
