ExtremeLink
™
4500 Product Specifications
USB 2.0 Ranger® 2304 Specifications
Ordering Information
The USB 2.0 Ranger® 2304 system includes a LEX, REX, USB Cable, Quick Start Guide, international power adapter with
country specific power cord and two year warranty. For more information, email
or call +1 604 638 3920.
PART #
NAME
DESCRIPTION
00-00347 USB 2.0 Ranger
®
2304 - NA
4-Port USB 2.0 100m Cat 5e Extender System, 100-240V Power Adapter, NA Power Cord
00-00348 USB 2.0 Ranger
®
2304 - EU
4-Port USB 2.0 100m Cat 5e Extender System, 100-240V Power Adapter, EU Power Cord
00-00349 USB 2.0 Ranger
®
2304 - UK
4-Port USB 2.0 100m Cat 5e Extender System, 100-240V Power Adapter, UK Power Cord
00-00350 USB 2.0 Ranger
®
2304 - AU
4-Port USB 2.0 100m Cat 5e Extender System, 100-240V Power Adapter, AU Power Cord
Specifications subject to change
without notification.
©2013
Icron Technologies Corp.
#90-01097-A01
RANGE
Direct Connect:
Up to 100m (330 ft) over solid core Cat 5e or better
USB DEVICE SUPPORT
Maximum USB 2.0 Throughput:
Up to 480Mbps
Maximum USB 1.1 Throughput:
Up to 12Mbps
Traffic Types:
All USB 2.0 and 1.1 Traffic Types
Device Types:
All USB 2.0 and 1.1 Device Types
LEX (LOCAL EXTENDER)
USB Connector:
1 x USB Type B Receptacle
Link Connector:
1 x RJ45
Dimensions:
100mm x 76mm x 26mm (3.9" x 3.0" x 1.0")
Enclosure Material:
Silver Anodized Aluminum
REX (REMOTE EXTENDER)
USB Connectors:
4 x USB Type A Receptacles
Link Connector:
1 x RJ45
Dimensions:
100mm x 76mm x 26mm (3.9" x 3.0" x 1.0")
Enclosure Material:
Silver Anodized Aluminum
Available Current:
Up to 600mA to each USB port
Power Supply:
100-240V AC input, 1A 24V DC Output
ENVIRONMENTAL
Operating Temperature:
0°C to 50°C (32°F to 122°F)
Storage Temperature:
-10°C to 60°C (14°F to 140°F)
Operating Humidity:
20% to 80% relative humidity, non-condensing
Storage Humidity:
10% to 90% relative humidity, non-condensing
COMPLIANCE
EMC:
FCC (Class B), CE (Class B)
Environmental:
RoHS2 (CE)
SUPPORT
Warranty:
2 years
