708FX2 Specifi cations
Switch Properties
Number of MAC Addresses:
8000
Aging Time : Programmable
Latency Typical: 2.9 μs
Switching Method : Store-and-Forward
Physical
Height:
2.3" (5.8cm)
Width: 6." (15.3cm)
Depth:
3.8" (9.6cm)
Weight (max): 1.65 lbs (0.75kg)
DIN-Rail Mount: 35mm
Electrical
Redundant Input Voltage:
10-30 VDC
Input Current (max): 330mA max @24VDC
N-TRON Power Supply:
NTPS-24-1.3 (1.3 A @24V)
Environmental
Operating Temperature:
-40 o C to 85 o C
Storage Temperature: -40 o C to 85 o C
Operating Humidity: 5% to 95%
(Non Condensing)
Operating Altitude:
0 to 10,000 ft.
Shock and Vibration (bulkhead mounted)
Shock:
200g @ 10ms
Vibration/Seismic: 50g, 5-200Hz, Triaxial
Reliability
MTBF:
>2 Million Hours
Network Media
10BaseT:
>Cat3 Cable
100BaseTX: >Cat5 Cable
100BaseFX
Multimode: 50-62.5/125μm
100BaseFXE
Singlemode:
7-10/125μm
Connectors
10/100BaseTX: Six (6) RJ-45 Copper Ports
100BaseFX: Two (2) SC or ST
Fiber Duplex Ports
Recommended Wiring Clearance
Front : 4" (10.16cm)
Side : 1" (2.54cm)
Regulatory Approvals
FCC/CE (CFR 47, Part 15, Subpart B, Class A)
EN 55011
ICES-003- Class A
EN61000-4-2/3/4/5/6/8/11, EN61000-6-2/4
UL /cUL: Class I, Div 2, Groups A, B, C, D and T4A
ANSI/ISA 12.12.01-2007
ATEX II 3 G Ex nC (DEMKO 03 ATEX 0316686U)
ABS Type Approval for Shipboard Applications
DNV Type Approval Certifi cation
EN50155 for Railway Applications
GOST-R Certifi ed
RoHS Compliant
Designed to comply with:
IEEE 1613 for Electric Utility Substations
NEMA TS1/TS2 for Traffi c Control
THE INDUSTRIAL NETWORK COMPANY
100 Mb Fiber Transceiver Characteristics
* Multimode Fiber Optic Cable
** Singlemode Fiber Optic Cable
Fiber Length 2km* 15km** 40km** 80km**
TX Power Min -19dBm -15dBm -5dBm -5dBm
RX Sensitivity Max -32dBm -29dBm -34dBm -34dBm
Wavelength 1310nm 1310nm 1310nm 1550nm
708FX2 Industrial Ethernet Switch Ordering Information
708FX2-XX Six 10/100BaseTX Ports, Two Multimode 100BaseFX Fiber Optic Ports
708FXE2-XX-YY Six 10/100BaseTX Ports, Two Singlemode 100BaseFX Fiber Optic Ports
700-PM Panel Mount Kit
NTPS-24-1.3 N-TRON Power Supply - (1.3 Amp @ 24VDC)
URMK 19" Universal Rack Mount Kit
Where: XX = ST or SC, YY = 15, 40 or 80 for Singlemode, Blank for Multimode E = Singlemode, and Blank Otherwise
