MAX2323/MAX2325
Triple/Dual-Mode
CDMA LNA/Mixers
8 _______________________________________________________________________________________
Table 3. Cellular LNA S Parameters in High-Gain High-Linearity Mode
FREQUENCY
(MHz)
S11
(MAG)
S11
(PHASE)
S21
(MAG)
S21
(PHASE)
S12
(MAG)
S12
(PHASE)
S22
(MAG)
S22
(PHASE)
700 0.623 -81.9 4.58 79.8 0.046 59.5 0.746 -29.5
750 0.627 -84.3 4.30 78.0 0.048 60.6 0.748 -30.2
800 0.629 -86.6 4.06 74.8 0.049 60.9 0.750 -30.9
850 0.631 -89.0 3.70 72.3 0.051 61.4 0.749 -31.1
900 0.632 -91.4 3.50 72.2 0.052 62.1 0.751 -32.3
950 0.635 -93.7 3.39 68.7 0.053 61.3 0.753 -33.0
1000 0.635 -96.0 3.08 66.3 0.053 62.7 0.753 -33.5
Table 4. PCS LNA S Parameters in High-Gain High-Linearity Mode
FREQUENCY
(MHz)
S11
(MAG)
S11
(PHASE)
S21
(MAG)
S21
(PHASE)
S12
(MAG)
S12
(PHASE)
S22
(MAG)
S22
(PHASE)
1700 0.671 -125.8 5.77 109.2 0.062 90.4 0.796 -50.3
1750 0.675 -126.9 5.66 109.3 0.064 89.9 0.800 -50.7
1800 0.685 -128.9 5.66 107.2 0.065 89.1 0.808 -51.7
1850 0.689 -130.8 5.56 106.3 0.066 88.7 0.812 -52.6
1900 0.694 -132.7 5.63 104.7 0.066 89.3 0.817 -53.6
1950 0.696 -134.3 5.54 102.7 0.066 90.6 0.820 -54.4
2000 0.700 -135.8 5.50 101.2 0.068 91.9 0.826 -55.3
2050 0.706 -137.3 5.41 99.0 0.070 92.6 0.832 -56.3
2100 0.712 -138.9 5.33 97.4 0.072 92.7 0.839 -57.4
2150 0.717 -140.4 5.24 95.0 0.073 93.0 0.844 -58.8
2200 0.718 -141.9 5.08 93.3 0.073 94.2 0.845 -60.1
2250 0.721 -143.2 4.99 91.2 0.074 96.2 0.849 -61.4
2300 0.724 -144.5 4.78 89.0 0.077 98.3 0.852 -62.9
2350 0.730 -145.6 4.64 87.7 0.081 99.2 0.858 -64.5
2400 0.735 -146.9 4.45 85.7 0.085 99.4 0.862 -66.5
2450 0.740 -147.9 4.33 85.4 0.087 99.3 0.867 -68.0
2500 0.746 -148.4 4.39 85.5 0.089 99.5 0.875 -69.1
