MAX2323/MAX2325
Triple/Dual-Mode
CDMA LNA/Mixers
_______________________________________________________________________________________ 7
FUNCTION CTRL PIN
MODES
BAND HGHL AMP HGLL AMP MGHL AMP LGHL AMP CDMA MIXER FM MIXER MODE G1 G2 SLEEP
Cellular Band CDMA
Mode, High Gain, High
Linearity (HGHL)
C √ √ 1 0 0 0
Cellular Band CDMA,
High Gain, Low Linearity
(Paging Mode) (HGLL)
C √ √ 1 0 1 0
Cellular Band, CDMA
Mode, Midgain (MGHL)
C √ √ 1 1 0 0
Cellular Band, CDMA
Mode, Low Gain (LGHL)
C √ √ 1 1 1 0
Cellular Band, FM Mode,
High Gain, Low Linearity
(HGLL)
C √ √ 0 0 1 0
Cellular Band, FM Mode,
Midgain
C √ √ 0 1 0 0
Cellular Band, FM Mode,
Low Gain
C √ √ 0 1 1 0
Shutdown — — — — — — — X X X 1
Cellular Band, FM Mode,
High Gain, High Linearity
(HGHL)
√ √ 0 0 0 0
Table 2. MAX2325 Operational Modes
X: Don’t care
