MAX2323/MAX2325
Triple/Dual-Mode
CDMA LNA/Mixers
______________________________________________________________________________________
13
______________________________________________________________________________________
13
DESIGNATION
QTY
DESCRIPTION
L7, L8
2
270nH
±2% inductors (0805)
Coilcraft 0805CS-271XGBC
L10
1
3.9nH
±0.3nH inductor (0603)
Murata LQG11A3N9S00
L11
1
330nH
±2% inductor (0805)
Coilcraft 0805CS-331XGBC
L12
1
2.7nH
±0.3nH inductor (0603)
Murata LQG11A2N7S00
R1, R4, R5,
R8, R10
5
1k
Ω ±5% resistors (0402)
R2
1
24.3k
Ω ±1% resistor (0402)
R3
1
20.0k
Ω ±1% resistor (0402)
R7
1
2.7k
Ω ±5% resistor (0402)
R11
1
8.2k
Ω ±5% resistor (0402)
T1
1
Balun transformer (B5F type)
Toko 458DB-1011
PLNAIN,
CLNAIN,
LOLIN, LOHIN,
CLNAOUT,
PLNAOUT,
CDMAOUT,
FMOUT
8
SMA connectors (PC edge mount)
EFJohnson 142-0701-801 or
Digi-Key J502-ND
PMIXIN,
CMIXIN
2
SMA connectors (vertical mount)
Digi-Key J500-ND
GND, VCC
2
Test points
Mouser 151-203
JU1, JU3, JU4,
JU7, JU9
5
3-pin headers
JU2, JU6, JU8,
JU10
4
2-pin headers
None
10
Shunts (JU1–JU4, JU6–JU10)
U1
1
MAX2323EGI (QFN-28)
None
1
MAX2323/MAX2325 data sheet
None
1
MAX2323 PC board
Component List
EV Kit Information
DESIGNATION
QTY
DESCRIPTION
C1, C4, C9,
C24, C29
5
0.01
µF ±10% ceramic caps (0402)
Murata GRM36X7R103K016 or
Taiyo Yuden EMK105B103KW
C2, C3,
C21, C22, C27
5
100pF
±5% ceramic caps (0402)
Murata GRM36COG101J050 or
Taiyo Yuden UMK105CH101JW
C17
1
2.7pF
±0.1pF ceramic cap (0402)
Murata GRM36COG2R7B050 or
Taiyo Yuden EVK105CH2R7JW
C7
1
3.0pF
±0.1pF ceramic cap (0402)
Murata GRM36COG3R0B050 or
Taiyo Yuden EVK105CH3R0JW
C8
1
1.5pF
±0.1pF ceramic cap (0402)
Murata GRM36COG1R5B050 or
Taiyo Yuden EVK105CH1R5BW
C12
1
0
Ω resistor (0402)
C6, C10
—
Not installed
C11, C18, C19,
C26, C28,
C32, C33
7
1000pF
±10% ceramic caps (0402)
Murata GRM36X7R102K050 or
Taiyo Yuden UMK105B102KW
C5, C14, C16
3
6800pF
±10% capacitors (0402)
Murata GRM36X7R682K025 or
Taiyo Yuden TMK105B682KW
C15
1
1.0pF
±0.1pF ceramic cap (0402)
Murata GRM36COG010B050 or
Taiyo Yuden EVK105CH010BW
C23, C25
2
5.6pF
±0.25pF ceramic caps (0402)
Murata GRM36COG5R6C050
C31
1
4.3pF
±0.1pF ceramic cap (0402)
Murata GRM36COG4R3B050 or
Taiyo Yuden EVK105CH4R3JW
L1
1
8.2nH
±5% inductor (0603)
Murata LQG11A8N2J00
L2, L4
2
1.8nH
±10% inductors (0603)
Coilcraft 0603CS-1N8XKBC
L3, L6
2
0
Ω resistors (0603)
L5
1
6.8nH
±5% inductor (0603)
Murata LQG11A6N8J00
