MAX1422
12-Bit, 20Msps, +3.3V, Low-Power ADC with
Internal Reference
4 _______________________________________________________________________________________
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
CLK, CLK ±330
PD -20 20 Input Current
OE -20 20
µA
Input Capacitance 10 pF
DIGITAL OUTPUTS (D0–D11)
Output Logic High V OH I OH = 200 µA
V D V DD
- 0.5
V DVDD V
Output Logic Low V OL I OL = -200 µA 0 0.5 V
Three-State Leakage -10 10 µA
Three-State Capacitance 2 pF
POWER REQUIREMENTS
Analog Supply Voltage V AVDD 3.138 3.3 3.465 V
Digital Supply Voltage V DVDD 2.7 3.3 3.63 V
Analog Supply Current I AVDD 39 46 mA
Analog Supply Current with
Internal Reference in Shutdown
REFIN = AGND 37 44 mA
Analog Shutdown Current PD = DV DD 20 µA
Digital Supply Current I DVDD 3 mA
Digital Shutdown Current PD = DV DD 20 µA
Power Dissipation P DISS Analog power dissipation 137 152 mW
Power-Supply Rejection Ratio PSRR (Note 9) ±1 mV/V
TIMING CHARACTERISTICS
Clock Frequency f
CLK
Figure 5 0.1 20 MHz
Clock High t CH Figure 5, clock period 50ns 25 ns
Clock Low t CL Figure 5, clock period 50ns 25 ns
Pipeline Delay (Latency) Figure 5 7
f CLK
Cycles
Aperture Delay t AD Figure 9 2 ns
Aperture Jitter t AJ Figure 9 2 ps
Data Output Delay t OD Figure 5 5 10 14 ns
Bus Enable Time t BE Figure 4 5 ns
Bus Disable Time t BD Figure 4 5 ns
ELECTRICAL CHARACTERISTICS (continued)
(V AVDD = V DVDD = +3.3V, AGND = DGND = 0, V IN = ±1.024V, differential input voltage at -0.5dB FS, +2.048V internal reference, f CLK =
20MHz (50% duty cycle), digital output load C L
≈ 10pF, T
A = T MIN to T MAX , unless otherwise noted. Typical values are at T A = +25°C.)
Note 1: Internal reference, REFIN bypassed to AGND with a combination of 0.22µF in parallel with 1nF capacitor.
Note 2: External +2.048V reference applied to REFIN.
Note 3: Internal reference disabled. VREFIN = 0, VREFP = +2.162V, VCML = +1.65V, and VREFN = +1.138V.
Note 4: IMD is measured with respect to either of the fundamental tones.
Note 5: Specifies the common-mode range of the differential input signal supplied to the MAX1422.
Note 6: VDIFF = VREFP - VREFN.
Note 7: Input bandwidth is measured at a 3dB level.
Note 8: VREFIN is internally biased to +2.048V through a 10kΩ resistor.
Note 9: Measured as the ratio of the change in mid-scale offset voltage for a ±5% change in VAVDD, using the internal reference.
