MAX1705/MAX1706

1- to 3-Cell, High-Current, Low-Noise,
Step-Up DC-DC Converters with Linear Regulator

18

______________________________________________________________________________________

4.0 ±0.1

0.30 ±0.05

0.8 ±0.05

0.30R MAX.

Bo

Ko

2.2 ±0.1

0.5 RADIUS

TYPICAL

A0

4.0 ±0.1

2.0 ±0.05

1.5 +0.1/-0.0 DIAMETER

1.75 ±0.1

1.0 ±0.1

A

8.0 ±0.3

3.5 ±0.05

1.0 MINIMUM

A

Ao = 3.1mm ±0.1
Bo = 2.7mm ±0.1
Ko = 1.2mm ±0.1

NOTE: DIMENSIONS ARE IN MM.

AND FOLLOW EIA481-1 STANDARD.

__________________________________________________Tape-and-Reel Information
