MAX2338

Triple/Dual-Mode CDMA LNA/Mixers

8

_______________________________________________________________________________________

Pin Description

PIN

NAME

FUNCTION

1

RLNA

LNA Bias–Setting Resistor Connection. For nominal bias, connect a 24k

Ω resistor to ground. The

value of this resistor sets the bias current for HGHL LNAs.

2

PLNAIN

High-Band RF Input. Requires a blocking capacitor which may be used as part of the input
matching network.

3, 8, 11, 18,

24, 25, 27,

Exposed

Paddle

GND

Ground Reference for RF, DC and Logic Inputs. Solder the exposed paddle evenly to the circuit
board ground plane.

4

CLNAIN

Low-Band RF Input. Requires a blocking capacitor which may be used as part of the input
matching network.

5

BAND

Band-Select Logic Input. LOW selects high-band (PCS), HIGH selects low-band (cellular).

6

LIN

Linearity-Select Logic Input. See Detailed Description for control modes.

7

GAIN

Gain-Select Logic Input. See Detailed Description for control modes.

9

LO/2

LO Divider-Select Input. LOW disables LO divider, HIGH selects divider in cellular and FM
modes. See Detailed Description for control modes.

10

LOIN

LO Input Port. Requires an external DC blocking capacitor.

12

PLOOUT

PCS LO Buffer Output Port. Internally matched to 100

Ω (nominal). Does not require a blocking

capacitor.

13

CLOOUT

Cell LO Buffer Output Port. Internally matched to 100

Ω (nominal). Does not require a blocking

capacitor. The output frequency is one half LOIN when LO/2 is floating or HIGH, and equal to
LOIN when LO/2 is LOW.

14

NC

No Connection

15

FMOUT

FM Mixer Output Port. Requires pullup inductor and DC blocking capacitor, which may be used
as part of the output matching network.

16

V

CC

Power Supply Pin. Bypass with capacitor as close to the pin as possible.

17

BUFFEN

LO Output Buffer Enable. Drive BUFFEN HIGH to power up the LO output buffer associated with
the selected band.

19, 20

IF-, IF+

Mixer Differential Outputs. Require pullup inductors and series capacitors which can be used as
part of the output matching network.

21

RBIAS

Bias Setting Resistor Connection. For nominal bias, connect a 24k

Ω resistor to ground. The value

of this resistor sets current for all blocks except HGHL LNA.

22

CMIXIN

Low-Band Mixer Input. Requires a blocking capacitor which may be used as part of the input
matching network.

23

PMIXIN

High-Band Mixer Input. Requires a blocking capacitor which may be used as part of the input
matching network.

26

PLNAOUT

High-Band LNA Output Port. Connect a pullup inductor to V

CC

and an external series blocking

capacitor which may be used as a part of the output matching network.

28

CLNAOUT

Low-Band LNA Output Port. Connect a pullup inductor to V

CC

and an external series blocking

capacitor which may be used as a part of the output matching network.
