MAX2338
Triple/Dual-Mode CDMA LNA/Mixers
2 _______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
DC ELECTRICAL CHARACTERISTICS
(V CC = +2.7V to +3.3V, R RBIAS = R RLNA = 24k Ω, BUFFEN = LOW, all RF and IF outputs connected to V
CC , no RF applied, T A = -40°C
to +85°C. Typical values are at +3.0V and T A = +25°C, unless otherwise noted. Refer to Operational Modes table for control logic.)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
V
CC
to GND..........................................................+0.3V to +4.3V
Digital Input Voltage to GND ......................-0.3V to (V CC + 0.3V)
LNA Input Level...............................................................1V peak
LO, Mixer Input Levels .....................................................+5dBm
Digital Input Current .........................................................±10mA
Continuous Power Dissipation (T
A = +70°C)
28-Pin QFN (derate 28.5mW/°C above T
A
= +70°C) .........2W
Operating Temperature Range ...........................-40°C to +85°C
Junction Temperature ......................................................+150°C
Storage Temperature Range .............................-65°C to +150°C
Lead Temperature (soldering, 10s) ................................ +300°C
PARAMETER CONDITIONS MIN TYP MAX UNITS
PCS CDMA MODES
High-gain, low-linearity mode 18 24
Operating Supply Current
High-gain, high-linearity mode 25 33
mA
CELLULAR CDMA MODE
Low-gain mode 19.5 25
High-gain, low-linearity mode 18 24 Operating Supply Current
High-gain, high-linearity mode 28 35
mA
FM MODE
Operating Supply Current 13.5 17 mA
SHUTDOWN MODE
Shutdown Supply Current 0.1 5 µA
ALL MODES
LO/2 = LOW 7.2 9.5
LO Buffer Supply Current BUFFEN = HIGH
LO/2 = HIGH 10.3
mA
Additional Operational Current
Divider Active
Cellular and FM mode; LO/2 = HIGH 1.2 mA
Digital Input Logic High 2.0 V
Digital Input Logic Low 0.6 V
Digital Input High Current 5 µA
Digital Input Low Current -25 µA
