MAX2645

3.4GHz to 3.8GHz SiGe
Low-Noise Amplifier/PA Predriver

2

_______________________________________________________________________________________

ABSOLUTE MAXIMUM RATINGS

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.

V

CC

to GND ...........................................................-0.3V to +6.0V

GAIN, SHDN, RFOUT to GND .....................0.3V to (V

CC

+ 0.3V)

RFIN Input Power (50

Ω source)........................................16dBm

Minimum R

BIAS

....................................................................10k

Continuous Power Dissipation (T

A

= +70°C)

10-Pin µMAX-EP
(derate 10.3mW/°C above T

A

= +70°C) ....................825mW

Operating Temperature Range ...........................-40°C to +85°C
Junction Temperature ......................................................+150°C
Storage Temperature Range .............................-65°C to +150°C
Lead Temperature (soldering, 10s) .................................+300°C

DC ELECTRICAL CHARACTERISTICS

(V

CC

= +3.0V to +5.5V, GAIN = SHDN = V

CC

, R

BIAS

= 20k

Ω, no RF signals applied, T

A

= -40°C to +85°C. Typical values are at V

CC

= +3.3V, T

A

= +25°C, unless otherwise indicated.)

PARAMETER

CONDITIONS

MIN

TYP

MAX

UNITS

Supply Voltage

3.0

5.5

V

GAIN = V

CC

9.2

10.9

R

BIAS

= 20k

Ω,

T

A

= +25°C

GAIN = GND

2.7

3.9

GAIN = V

CC

11.6

R

BIAS

= 20k

Ω,

T

A

= -40°C to +85°C

GAIN = GND

4.0

GAIN = V

CC

12

Operating Supply Current

R

BIAS

= 15k

Ω,

T

A

= +25°C

GAIN = GND

3.6

mA

Shutdown Supply Current

SHDN = GND

0.1

2

µA

Input Logic Voltage High

GAIN, SHDN

2.0

V

Input Logic Voltage Low

GAIN, SHDN

0.6

V

GAIN = SHDN = V

CC

1

Input Logic Bias Current

GAIN = SHDN = GND

-10

µA
