����������������������������������������������������������������� Maxim Integrated Products 2
MAX2670
GPS/GNSS Front-End Amplifier
RFOUT1, RFOUT2, EXTCAP to GND ....... -0.3V to (V
CC
+ 0.5V)
RFIN1 Input Power (50I source) .................................. +15dBm
GAIN_SELECT to GND ............................. -0.3V to (V
CC
+ 0.3V)
Continuous Power Dissipation (T
A
= +70NC)
TDFN (derate 18.5mW/NC above +70NC) ..................1481mW
Operating Ambient Temperature Range ......... -40NC to +105NC
Maximum Junction Temperature .....................................+150NC
Storage Temperature Range ............................ -65NC to +150NC
Lead Temperature (soldering, 10s) ................................+300NC
Soldering Temperature (reflow) ......................................+260NC
ABSOLUTE MAXIMUM RATINGS
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional opera-
tion of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect device reliability.
DC ELECTRICAL CHARACTERISTICS
(V
IN
= 3.0V to 5.5V, T
A
= -40NC to +105NC. Typical values are at +5.0V and at T
A
= +25NC. Pin 7 open, unless otherwise noted.)
(Note 1)
AC ELECTRICAL CHARACTERISTICS
(V
CC
= 3.0V to 5.5V, P
IN
= -40dBm, f
IN
= 1575MHz, T
A
= -40NC to +105NC. Typical values are at 5.0V and at T
A
= +25NC. Input
matched to 50I, load = 50I, pin 7 open, unless otherwise noted.) (Note 1)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Supply Voltage V
CC
3.0 5.5 V
Supply Current I
CC
T
A
= +25NC 15.0 25 30
mA
T
A
= -40NC to 105NC 30
Gain-Select Input Current I
IL
V
IL
= 0V 20 100 F A
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Operation Frequency f
RF
1575 MHz
AMP 1 Gain |S
21
|
50I source with no input match (Note 2) 14.5 16.7 19
dB
50I source with input match 17.8
AMP 1 Gain Variation Over
Temperature
0.3 dB
AMP 1 Noise Figure NF No input match (Notes 2, 3) 1 dB
AMP 1 Input Third-Order
Intercept Point
IIP3
Two tones at 1574.5MHz and 1575.5MHz,
-35dBm per tone
-12 dBm
AMP 1 Input 1dB Compression
Point
50I source with no input match (Note 2) -19 dBm
AMP 1 Input Return Loss |S
11
| No input match (Note 2) -4.4 dB
AMP 1 Output Return Loss |S
22
| -14.5 dB
AMP 1 Reverse Isolation |S
12
| -33 dB
AMP 2 Gain |S
21
| 14.5 17 21 dB
AMP 2 Gain Step Gain change when pin 7 is shorted to GND -2.5 -3.4 -4.0 dB
AMP 2 Gain Variation Over
Temperature
1 dB
AMP 2 Noise Figure NF (Note 3) 2.0 dB
