General Description
The MAX3030E–MAX3033E family of quad RS-422
transmitters send digital data transmission signals over
twisted-pair balanced lines in accordance with TIA/EIA-
422-B and ITU-T V.11 standards. All transmitter outputs
are protected to ±15kV using the Human Body Model.
The MAX3030E–MAX3033E are available with either a
2Mbps or 20Mbps guaranteed baud rate. The 2Mbps
baud rate transmitters feature slew-rate-limiting to mini-
mize EMI and reduce reflections caused by improperly
terminated cables.
The 20Mbps baud rate transmitters feature low-static
current consumption (I
CC
< 100µA), making them ideal
for battery-powered and power-conscious applications.
They have a maximum propagation delay of 16ns and a
part-to-part skew less than 5ns, making these devices
ideal for driving parallel data. The MAX3030E–
MAX3033E feature hot-swap capability that eliminates
false transitions on the data cable during power-up or
hot insertion.
The MAX3030E–MAX3033E are low-power, ESD-pro-
tected, pin-compatible upgrades to the industry-stan-
dard 26LS31 and SN75174. They are available in
space-saving 16-pin TSSOP and SO packages.
Applications
Telecom Backplanes
V.11/X.21 Interface
Industrial PLCs
Motor Control
Features
♦ Meet TIA/EIA-422-B (RS-422) and ITU-T V.11
Recommendation
♦ ±15kV ESD Protection on Tx Outputs
♦ Hot-Swap Functionality
♦ Guaranteed 20Mbps Data Rate (MAX3030E,
MAX3032E)
♦ Slew-Rate-Controlled 2Mbps Data Rate
(MAX3031E, MAX3033E)
♦ Available in 16-Pin TSSOP and Narrow SO
Packages
♦ Low-Power Design (<330µW, V
CC
= 3.3V Static)
♦ +3.3V Operation
♦ Industry-Standard Pinout
♦ Thermal Shutdown
MAX3030E–MAX3033E
±15kV ESD-Protected, 3.3V Quad
RS-422 Transmitters
________________________________________________________________ Maxim Integrated Products 1
Ordering Information
19-2671; Rev 0; 10/02
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.
PART TEMP RANGE PIN-PACKAGE
MAX3030ECSE 0°C to +70°C 16 SO (Narrow)
MAX3030ECUE 0°C to +70°C 16 TSSOP
MAX3030EESE -40°C to +85°C 16 SO (Narrow)
MAX3030EEUE -40°C to +85°C 16 TSSOP
MAX3031ECSE 0°C to +70°C 16 SO (Narrow)
MAX3031ECUE 0°C to +70°C 16 TSSOP
MAX3031EESE -40°C to +85°C 16 SO (Narrow)
MAX3031EEUE -40°C to +85°C 16 TSSOP
MAX3032ECSE 0°C to +70°C 16 SO (Narrow)
MAX3032ECUE 0°C to +70°C 16 TSSOP
MAX3032EESE -40°C to +85°C 16 SO (Narrow)
MAX3032EEUE -40°C to +85°C 16 TSSOP
MAX3033ECSE 0°C to +70°C 16 SO (Narrow)
MAX3033ECUE 0°C to +70°C 16 TSSOP
MAX3033EESE -40°C to +85°C 16 SO (Narrow)
MAX3033EEUE -40°C to +85°C 16 TSSOP
16
15
14
13
12
11
10
9
1
2
3
4
5
6
7
8
DI1 V CC
DI4
DO4+
DO4-
DO3-
DO3+
DI3
TOP VIEW
MAX3030E/
MAX3031E
TSSOP/SO
DO1+
DO1-
DO2+
EN
DO2-
DI2
GND
EN
16
15
14
13
12
11
10
9
1
2
3
4
5
6
7
8
DI1 V CC
DI4
DO4+
DO4-
DO3-
DO3+
DI3
MAX3032E/
MAX3033E
TSSOP/SO
DO1+
DO1-
DO2+
EN1&2
DO2-
DI2
GND
EN3&4
Pin Configurations
