DS1086
DS1086 Spread-Spectrum EconOscillator
2
_____________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
RECOMMENDED DC OPERATING CONDITIONS
(V
CC
= 5V ±5%, T
A
= 0°C to +70°C.)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Supply Voltage
V
CC
(Note 1)
4.75
5.00
5.25
V
High-Level Input Voltage
(SDA, SCL)
V
IH
0.7 x
V
CC
V
CC
+
0.3
V
Low-Level Input Voltage
(SDA, SCL)
V
IL
-0.3
0.3 x
V
CC
V
High-Level Input Voltage
(SPRD,
PDN, OE)
V
IH
2
V
CC
+
0.3
V
Low-Level Input Voltage
(SPRD,
PDN, OE)
V
IL
-0.3
0.8
V
DC ELECTRICAL CHARACTERISTICS
(V
CC
= 5V ±5%, T
A
= 0°C to +70°C.)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
High-Level Output Voltage (OUT)
V
OH
I
OH
= -4mA, V
CC
= min
2.4
V
Low-Level Output Voltage (OUT)
V
OL
I
OL
= 4mA
0.4
V
High-Level Input Current
I
IH
V
CC
= 5.25V
1
µA
Low-Level Input Current
I
IL
V
IL
= 0
-1
µA
Supply Current (Active)
I
CC
C
L
= 15pF (output at default frequency)
35
mA
Standby Current (Power-Down)
I
CCQ
Power-down mode
10
µA
Voltage on V
CC
Relative to Ground ......................-0.5V to +6.0V
Voltage on SPRD,
PDN, OE, SDA,
SCL Relative to Ground (See Note 1).......-0.5 to (V
CC
+ 0.5V)
Operating Temperature Range...............................0°C to +70°C
Storage Temperature Range .............................-55°C to +125°C
Soldering Temperature ..................See IPC/JEDEC J-STD-020A
Note 1:
This voltage must not exceed 6.0V.
