DS4426
Quad-Channel, I
2
C-Margining IDACs with
Three Channels of Power-Supply Tracking
2 _______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
RECOMMENDED OPERATING CONDITIONS
(T A = -40°C to +85°C.)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
Voltage Range on SDA, SCL Relative to GND ......-0.5V to +6.0V
Voltage Range on V
CC Relative to GND ...............-0.5V to +6.0V
Voltage Range on A0, A1, FS[3:0], GAIN[3:1],
INN[3:1], INP[3:1], THR[3:1], and OUT[3:0]
Relative to GND ......................................-0.5V to (V
CC
+ 0.5V)*
Operating Temperature Range ...........................-40 °C to +85°C
Storage Temperature Range .............................-55 °C to +125°C
Soldering Temperature...........................Refer to the IPC/JEDEC
J-STD-020 Specification.
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Supply Voltage V CC (Note 1) 2.7 5.5 V
Input Logic 1
(SDA, SCL, A0, A1)
V IH
0.7 x
V CC
V CC +
0.3
V
Input Logic 0
(SDA, SCL, A0, A1)
V IL -0.3
0.3 x
V CC
V
Full-Scale Resistor Values R FS[3:0] (Note 2) 40 160 k
DC ELECTRICAL CHARACTERISTICS
(V
CC
= +2.7V to +5.5V, T
A
= -40°C to +85°C.)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Supply Current I CC V CC = +5.5V (Note 3) 0.9 mA
Input Leakage Current
(SDA, SCL)
I IL V CC = +5.5V -1 +1 μA
RFS Voltage V RFS T A = +25°C 0.940 0.990 1.040 V
Reference Voltage V REF 1.24 V
Temperature Coefficient ±100 ppm/°C
Output Leakage Current (SDA) I L -1 +1 μA
V OL = +0.4V 3
Output-Current Low (SDA) I OL
V OL = +0.6V 6
mA
I/O Capacitance C I/O 10 pF
DAC OUTPUT CURRENT CHARACTERISTICS
(V CC = +2.7V to +5.5V, T A = -40°C to +85°C.)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
DC source, V
OUT
measured at +1.2V 0.33 Output Current Variation Due to
Power-Supply Change
DC sink, V OUT measured at +1.2V 0.33
%/V
DC source, V CC = +3.6V 0.15 Output Current Variation Due to
Output-Voltage Change
DC sink, V CC = +3.6V 0.30
%/V
* Not to exceed +6.0V.
