background image

DS1337 I

2

C Serial Real-Time Clock

10 of 15

Table 3. Alarm Mask Bits

ALARM 1 REGISTER MASK BITS

(BIT 7)

DY/

DT

A1M4 A1M3 A1M2 A1M1

ALARM RATE

X

1

1

1

1

Alarm once per second

X

1

1

1

0

Alarm when seconds match

X

1

1

0

0

Alarm when minutes and seconds match

X

1

0

0

0

Alarm when hours, minutes, and seconds match

0 0 0 0 0

Alarm when date, hours, minutes, and seconds
match

1

0

0

0

0

Alarm when day, hours, minutes, and seconds match

ALARM 2 REGISTER MASK BITS

(BIT 7)

DY/

DT

A2M4 A2M3 A2M2

ALARM RATE

X

1

1

1

Alarm once per minute (00 seconds of every minute)

X

1

1

0

Alarm when minutes match

X

1

0

0

Alarm when hours and minutes match

0

0

0

0

Alarm when date, hours, and minutes match

1

0

0

0

Alarm when day, hours, and minutes match

SPECIAL-PURPOSE REGISTERS

The DS1337 has two additional registers (control and status) that control the RTC, alarms, and square-wave
output.

Control Register (0Eh)

Bit 7

Bit 6

Bit 5

Bit 4

Bit 3

Bit 2

Bit 1

Bit 0

EOSC

0 0

RS2

RS1

INTCN

A2IE

A1IE


Bit 7:

Enable Oscillator (EOSC). This active-low bit when set to logic 0 starts the oscillator. When this bit is set to

logic 1, the oscillator is stopped. This bit is enabled (logic 0) when power is first applied.

Bits 4 and 3: Rate Select (RS2 and RS1). These bits control the frequency of the square-wave output when the
square wave has been enabled. The table below shows the square-wave frequencies that can be selected with the
RS bits. These bits are both set to logic 1 (32kHz) when power is first applied.

Square-Wave Output Frequency

RS2 RS1

SQUARE-WAVE

OUTPUT FREQUENCY

0 0

1Hz

0 1

4.096kHz

1 0

8.192kHz

1 1

32.768kHz

Bit 2: Interrupt Control (INTCN). This bit controls the relationship between the two alarms and the interrupt output
pins. When the INTCN bit is set to logic 1, a match between the timekeeping registers and the alarm 1 registers l
activates the

INTA pin (provided that the alarm is enabled) and a match between the timekeeping registers and the

alarm 2 registers activates the SQW/

INTB pin (provided that the alarm is enabled). When the INTCN bit is set to

logic 0, a match between the timekeeping registers and either alarm 1 or alarm 2 registers activates the

INTA pin
