DS1682
7 of 15
CONFIGURATION REGISTER
MSb LSb
0 AF WDF WMDF AOS RE AP ECMSB
Note:
The configuration register is not stored in EEPROM until an event becomes inactive. RE does not
need to be stored in EEPROM to reset the device.
AF (Alarm Flag) – The alarm flag is set to a 1 when the ETC value matches the alarm register. Once the
AF bit is set to a 1, it cannot be set to a 0. This bit is read-only.
WDF (Write Disable Flag) – When the write disable command is written to AAh twice at memory
location 1Eh, the WDF is set to a 1 and cannot be cleared or reset. When WDF is set to a 1, the alarm,
ETC, and event counter registers are read-only. This bit is read-only.
WMDF (Write-Memory Disable Flag) – When the write-memory disable command is written to F0h
twice at memory location 1Fh, the WMDF is set to a 1 and cannot be reset or cleared. Once the WMDF is
set to a 1, the 10-byte user memory becomes read-only. This bit is read-only.
AOS (Alarm Output Select) – If AOS is 0 and AF is true, the DS1682 activates the ALARM output
during an event when AF becomes true. The DS1682 also activates the ALARM output by pulling the
pin low four times at power-up, at the start and end of an event, or when the ALARM pin is pulled low
and released. This output mode can be used to flash an LED or to communicate with another device to
indicate that an alarm has occurred. AP has no affect on the output when AOS is 0.
If AOS is a 1 and AF is true, the ALARM output is constant when the alarm is active. AP determines the
polarity of the output.
RE (Reset Enable) – The reset enable bit allows the device to be reset by enabling the reset command.
The sections of the DS1682 that are reset are then dependent on the value in the WDF. With the WDF set
to 0 and the reset enable bit set to a 1, the reset command clears the ETC, EEPROM, and event counter.
When the reset enable bit is set to a 0, the reset command is disabled.
AP (Alarm Polarity) – When the alarm polarity bit in the configuration register is set to 0, the ALARM
output is high impedance during the period that the value in the ETC is less than the alarm register value.
When the ETC matches the alarm value, the ALARM pin is driven low. If the AP bit is set to a 1, the
ALARM output is driven low during the period that the ETC is less than the alarm value. When the ETC
matches the alarm value, the ALARM pin becomes high impedance. The AP bit has no affect if AOS is
set to a 0.
ECMSB (Event Counter MSB) – This bit is read-only.
USER MEMORY
There are 10 bytes of user-programmable, EEPROM memory. Once the write-memory disable flag is set
to a 1, the memory becomes read-only. User memory is not stored in EEPROM until an event becomes
inactive.
