DS1315
041697 21/22
DS1315 TIME CHIP 16–PIN SOIC
A
F C
E phi
J
G K
L
H B
1
PKG 16–PIN
DIM MIN MAX
A IN.
MM
0.402
10.21 0.412
10.46
B IN.
MM
0.290
7.37 0.300
7.65
C IN.
MM
0.089
2.26 0.095
2.41
E IN.
MM
0.004
0.102 0.012
0.30
F IN.
MM
0.094
2.38 0.105
2.68
G IN.
MM
0.050 BSC
1.27 BSC
H IN
MM
0.398
10.11 0.416
10.57
J IN
MM
0.009
0.229 0.013
0.33
K IN.
MM
0.013
0.33 0.019
0.48
L IN
MM
0.016
0.40 0.040
1.02
PHI 0 ° 8 °
