DS4266
DDR Clock Oscillator
Maxim cannot assume responsibility for use of any circuitry other than circuitry entirely embodied in a Maxim product. No circuit patent licenses are
implied. Maxim reserves the right to change the circuitry and specifications without notice at any time.
6 _____________________Maxim Integrated Products, 120 San Gabriel Drive, Sunnyvale, CA 94086 408-737-7600
© 2008 Maxim Integrated Products
is a registered trademark of Maxim Integrated Products, Inc.
Chip Information
SUBSTRATE CONNECTED TO GROUND
PROCESS: BiPOLAR SiGe
THETA-JA (°C/W)
90
Selector Guide
+
Denotes a lead-free/RoHS-compliant package. The lead finish is JESD97 category e4 (Au over Ni) and is compatible with both lead-
based and lead-free soldering processes.
PART
FREQUENCY (NOM)
(MHz)
FREQUENCY
STABILITY (ppm)
OUTPUT TYPE
TOP
MARK
DS4266D+ 266
±50 LVDS 66D
DS4266P+ 266
±50 LVPECL 66P
Thermal Information
1
2
3
6
5
4
TOP VIEW
OE
N.C.
N.C.
N.C.
N.C.
N.C.
GND
V
CC
OUTN
OUTP
+
(5.00mm
× 3.20mm × 1.49mm)
DS4266
*EP
*EXPOSED PAD
Pin Configuration
PACKAGE TYPE
PACKAGE CODE
DOCUMENT NO.
10 LCCC
—
Package Information
For the latest package outline information and land patterns, go
to
www.maxim-ic.com/packages
.
