DS4266
DDR Clock Oscillator
_______________________________________________________________________________________ 3
ELECTRICAL CHARACTERISTICS (continued)
(V CC = 3.135V to 3.465V, T A = -40°C to +85°C, unless otherwise noted.)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
LVDS
Output High Voltage V OHLVDSO 100 differential load (Note 1) 1.475 V
Output Low Voltage V OLLVDSO 100 differential load (Note 1) 0.925 V
Differential Output Voltage |V
ODLVDSO
| 100 differential load 250 425 mV
Output Common-Mode Voltage
Variation
V LVDSOCOM 100 differential load 150 mV
Change in Differential Magnitude
or Complementary Inputs
|V
ODLVDSO
| 100 differential load 25 mV
Offset Output Voltage V OFFLVDSO 100 differential load (Note 1) 1.125 1.275 V
Differential Output Impedance R OLVDSO 80 140
L VSSLVDSO
OUTN or OUTP shorted to ground and
measure the current in the shorting path
40
Output Current
L LVDSO OUTN or OUTP shorted together 6.5
mA
Output Rise Time (Differential) t RLVDSO 20% to 80% 175 ps
Output Fall Time (Differential) t FLVDSO 80% to 20% 175 ps
Duty Cycle D
CYCLE_LVDS
48 52 %
Propagation Delay from OE Going
Low to Logical 1 at OUTP
t
PA1
200 ns
Propagation Delay from OE Going
High to Output Active
t P1A 200 ns
LVPECL
Output High Voltage V OH
Output connected to 50 at PECL_BIAS
at V CC - 2.0V
V CC -
1.085
V CC -
0.88
V
Output Low Voltage V OL
Output connected to 50 at PECL_BIAS
at V CC - 2.0V
V CC -
1.825
V CC -
1.62
V
Differential Voltage V DIFF_PECL
Output connected to 50 at PECL_BIAS
at V CC - 2.0V
0.595 0.710 V
Rise Time t R-PECL 200 ps
Fall Time t F-PECL 200 ps
Duty Cycle D CYCLE_PECL 48 52 %
Propagation Delay from OE Going
Low to Output High Impedance
t PAZ 200 ns
Propagation Delay from OE Going
High to Output Active
t PZA 200 ns
Note 1: All voltages referenced to ground.
Note 2: AC parameters are guaranteed by design and not production tested.
Note 3: Frequency stability is calculated as:
Δf
TOTAL = Δf
TEMP + Δf
VCC x (3.3 x 5%) + Δf
LOAD + Δf
AGING .
