MAX14752/MAX14753
8-Channel/Dual 4-Channel
72V Analog Multiplexers
_______________________________________________________________________________________ 7
Test Circuits/Timing Diagrams/Truth Tables (continued)
MAX14752
10k Ω
50 Ω
V OUT
OUT
IN1–IN6
IN0 +10V
IN7 +10V
10k Ω
OUTA
INA3 +10V
V
SS
GND
-35V
+35V
V DD S2
EN
S0
S1
MAX14753
INA1–INA2
INB0–INB3
INA0 +10V
V SS GND
-35V
+35V
V DD
S_
0V
50%
t R < 20ns
t F < 20ns
V OUT , V OUTA
t TRANS
90%
0V
+3.3V
SWITCH
OUTPUT
+3.3V
50 Ω
S1
EN
S0
+3.3V V OUTA
Figure 5. Transition Time
MAX14752
10k Ω
50 Ω
V OUT OUT
IN0–IN7 +10V
V SS GND
-35V
+35V
V DD EN +3.3V
S0
S2
S1
S_
0V
50%
t R < 20ns
t F < 20ns
SWITCH
OUTPUT
V OUT
t BBM
80%
+3.3V
0V
Figure 6. Break-Before-Make Interval
