MAX9595
Audio/Video Switch for Dual SCART Connector
4 _______________________________________________________________________________________
ELECTRICAL CHARACTERISTICS (continued)
(V 12 = 12V, V VID = V AUD = 5V; 0.1µF X5R capacitor in parallel with a 10µF aluminum electrolytic capacitor from V AUD to GNDAUD,
V 12 to GNDAUD, and V VID to GNDVID; SET = 100kΩ nominal, R LOAD = 150Ω, T A = 0°C to +70°C, unless otherwise noted. Typical
values are at T A = +25°C.) (Note 1)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNIT
Single-ended inputs, f = 1kHz, THD < 1% 3
Input Signal Amplitude
(Measured from Application
Input)
V IN_AC ENC inputs single-ended, f = 1kHz,
THD < 1%
1.31
V RMS
Single ended: VCR_INR, VCR_INL, TV_INR,
TV_INL
0.1
Input Resistance (Measured at
Parts Input)
R IN
Encoder, ENC _ INL, ENC_INR 0.1
MΩ
Output DC Level V
OUT_DC
V
IN
= 0V
0.5 x
V
12
V
Signal-to-Noise Ratio (Measured
from Application Input)
SNR_A
f = 1.0kHz, 1V RMS application input,
gain = 0dB, 20Hz to 20kHz
95 dB
R LOAD = 10kΩ, f = 1.0kHz, 0.5V RMS output 0.004 Total Harmonic Distortion Plus
Noise
THD+N
R LOAD = 10kΩ, f = 1.0kHz, 2V RMS output 0.004
%
Output Impedance ZO f = 1kHz 1 Ω
1.414V P-P input, programmable gain to TV
SCART volume control range extends from
-56dB to +6dB 1.5 2 2.5
Volume Attenuation Step ASTEP
1.414V P-P input, programmable gain to VCR
audio extends from -6dB to +6dB
5.5 6 6.5
dB
From V 12, f = 1kHz, 0.5V P-P ,
(C AUD_BIAS = 47µF), gain = 0dB
75
Power-Supply Rejection Ratio PSRR_A
From V AUD , f = 1kHz, 0.5V P-P, V AUD ≥
+4.75V, V AUD ≤ +5.25V, gain = 0dB
75
dB
Mute Suppression M_SPR_A
f = 1kHz, 0.5V
RMS
input, set through I 2 C, see
register 1 for loading register details
90 dB
Audio Clipping Level VCLIP
f = 1kHz, 2.5V RMS input, gain = 6dB,
THD < 1%
3.6 V RMS
Left-to-Right Crosstalk XTLK_LR f = 1kHz, 0.5V RMS input, gain = 0dB 80 dB
Crosstalk XTLK_CC
TV SCART to VCR SCART or VCR SCART to
TV SCART, f = 1kHz, 0.5V
RMS
input, gain =
0dB
90 dB
